EVAL BOARD, ISOLATED FLYBACK CONVERTER ROHS COMPLIANT: YES

Find alt
STEVAL-VP318L1F

STEVAL-VP318L1F

Active
STMicroelectronics

EVAL BOARD, ISOLATED FLYBACK CONVERTER ROHS COMPLIANT: YES

Find alt

Description

General part information

STEVAL Series

The STEVAL-BFA001V1B is an industrial reference design kit designed for condition monitoring (CM) and predictive maintenance (PdM).

The hardware development kit consists of an industrial sensor board (STEVAL-IDP005V1), an adapter for the ST-LINK/V2-1 programming and debugging tool (STEVAL-UKI001V1), a 0.050" 10-pin flat cable, a 4-pole cable mount connector plug with male contacts and an M12 female connector with a 2 m cable.

The firmware package includes dedicated algorithms for advanced time and frequency domain signal processing and analysis of the 3D digital accelerometer with 3 kHz flat bandwidth. The package includes drivers for pressure, relative humidity and temperature sensor monitoring. Audio algorithms for acoustic emission (AE) are also part of the package.

Technical Specifications

Parameters and characteristics for this part

SpecificationSTEVAL-VP318L1F
Board TypeFully Populated
ContentsBoard
Current - Output1.2 A
Frequency - Switching60 kHz
Isolated Output Count2 count
Main PurposePrimary and Secondary Side, AC/DC
Output TypeIsolated
Power - Output18 W
Regulator TopologyFlyback
Supplied ContentsBoard(s)
Total Output Count2
Utilized IC / PartVIPer318L
Voltage - Input (AC) Maximum265 VAC
Voltage - Input (AC) Minimum85 VAC
Voltage - Output15 V
