SLM-107-01-S-S

Active

Samtec Inc.

CONN RCPT 7POS 0.05 GOLD PCB

Search across all available documentation for this part.

Active

Samtec Inc.

CONN RCPT 7POS 0.05 GOLD PCB

Technical Specifications

Parameters and characteristics for this part

Specification	SLM-107-01-S-S

Connector Type	Receptacle
Contact Finish - Mating	Gold
Contact Finish - Post	Tin
Contact Finish Thickness - Mating	30 Áin
Contact Finish Thickness - Mating	0.76 Ám
Contact Length - Post	2.92 mm
Contact Length - Post	0.115 in
Contact Material	Phosphor Bronze
Contact Shape	Rectangular
Contact Type	Forked
Fastening Type	Push-Pull
Insulation Color	Black
Insulation Height	4.57 mm
Insulation Height	0.18 "
Insulation Material	Liquid Crystal Polymer (LCP)
Mounting Type	Through Hole
Number of Positions	7
Number of Positions Loaded	All
Number of Rows	1
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Pitch - Mating	0.05 in
Pitch - Mating	1.27 mm
Termination	Solder

Part	Insulation Color	Contact Shape	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Material	Number of Rows	Contact Type	Fastening Type	Pitch - Mating	Pitch - Mating	Number of Positions	Contact Finish - Post	Insulation Height	Insulation Height	Termination	Contact Length - Post	Contact Length - Post	Insulation Material	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]	Connector Type	Contact Finish - Mating	Number of Positions Loaded	Contact Finish Thickness - Post	Contact Finish Thickness - Post
Samtec Inc. SLM-107-01-L-D	Black	Rectangular	2.54 mm	0.1 in	10 çin	0.25 çm	Phosphor Bronze	2	Forked	Push-Pull	0.05 in	1.27 mm	14	Tin	4.57 mm	0.18 "	Solder	2.92 mm	0.115 in	Liquid Crystal Polymer (LCP)	Through Hole	-55 °C	125 °C	Receptacle	Gold	All
Samtec Inc. SLM-107-01-G-S	Black	Rectangular			20 µin	0.51 µm	Phosphor Bronze	1	Forked	Push-Pull	0.05 in	1.27 mm	7	Gold	4.57 mm	0.18 "	Solder	2.92 mm	0.115 in	Liquid Crystal Polymer (LCP)	Through Hole	-55 °C	125 °C	Receptacle	Gold	All	3 µin	0.076 µm
Samtec Inc. SLM-107-01-F-D	Black	Rectangular	2.54 mm	0.1 in	3 µin	0.076 µm	Phosphor Bronze	2	Forked	Push-Pull	0.05 in	1.27 mm	14	Tin	4.57 mm	0.18 "	Solder	2.92 mm	0.115 in	Liquid Crystal Polymer (LCP)	Through Hole	-55 °C	125 °C	Receptacle	Gold	All
Samtec Inc. SLM-107-01-S-S	Black	Rectangular			30 Áin	0.76 Ám	Phosphor Bronze	1	Forked	Push-Pull	0.05 in	1.27 mm	7	Tin	4.57 mm	0.18 "	Solder	2.92 mm	0.115 in	Liquid Crystal Polymer (LCP)	Through Hole	-55 °C	125 °C	Receptacle	Gold	All
