SLM-107-01-G-S

Active

Samtec Inc.

CONN, RCPT, 7POS, 1ROW, 1.27MM ROHS COMPLIANT: YES

Search across all available documentation for this part.

Active

Samtec Inc.

CONN, RCPT, 7POS, 1ROW, 1.27MM ROHS COMPLIANT: YES

Technical Specifications

Parameters and characteristics for this part

Specification	SLM-107-01-G-S

Connector Type	Receptacle
Contact Finish - Mating	Gold
Contact Finish - Post	Gold
Contact Finish Thickness - Mating	0.51 µm
Contact Finish Thickness - Mating	20 µin
Contact Finish Thickness - Post	3 µin
Contact Finish Thickness - Post	0.076 µm
Contact Length - Post	2.92 mm
Contact Length - Post	0.115 in
Contact Material	Phosphor Bronze
Contact Shape	Rectangular
Contact Type	Forked
Fastening Type	Push-Pull
Insulation Color	Black
Insulation Height	4.57 mm
Insulation Height	0.18 "
Insulation Material	Liquid Crystal Polymer (LCP)
Mounting Type	Through Hole
Number of Positions	7
Number of Positions Loaded	All
Number of Rows	1
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Pitch - Mating	0.05 in
Pitch - Mating	1.27 mm
Termination	Solder

Part	Insulation Color	Contact Shape	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Material	Number of Rows	Contact Type	Fastening Type	Pitch - Mating	Pitch - Mating	Number of Positions	Contact Finish - Post	Insulation Height	Insulation Height	Termination	Contact Length - Post	Contact Length - Post	Insulation Material	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]	Connector Type	Contact Finish - Mating	Number of Positions Loaded	Contact Finish Thickness - Post	Contact Finish Thickness - Post
Samtec Inc. SLM-107-01-L-D	Black	Rectangular	2.54 mm	0.1 in	10 çin	0.25 çm	Phosphor Bronze	2	Forked	Push-Pull	0.05 in	1.27 mm	14	Tin	4.57 mm	0.18 "	Solder	2.92 mm	0.115 in	Liquid Crystal Polymer (LCP)	Through Hole	-55 °C	125 °C	Receptacle	Gold	All
Samtec Inc. SLM-107-01-G-S	Black	Rectangular			20 µin	0.51 µm	Phosphor Bronze	1	Forked	Push-Pull	0.05 in	1.27 mm	7	Gold	4.57 mm	0.18 "	Solder	2.92 mm	0.115 in	Liquid Crystal Polymer (LCP)	Through Hole	-55 °C	125 °C	Receptacle	Gold	All	3 µin	0.076 µm
Samtec Inc. SLM-107-01-F-D	Black	Rectangular	2.54 mm	0.1 in	3 µin	0.076 µm	Phosphor Bronze	2	Forked	Push-Pull	0.05 in	1.27 mm	14	Tin	4.57 mm	0.18 "	Solder	2.92 mm	0.115 in	Liquid Crystal Polymer (LCP)	Through Hole	-55 °C	125 °C	Receptacle	Gold	All
Samtec Inc. SLM-107-01-S-S	Black	Rectangular			30 Áin	0.76 Ám	Phosphor Bronze	1	Forked	Push-Pull	0.05 in	1.27 mm	7	Tin	4.57 mm	0.18 "	Solder	2.92 mm	0.115 in	Liquid Crystal Polymer (LCP)	Through Hole	-55 °C	125 °C	Receptacle	Gold	All

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

7 Position Receptacle Connector 0.050" (1.27mm) Through Hole Gold
