IPBD-08-D - IPBD-08-D

IPBD-08-D

Active
Samtec Inc.

CONNECTOR ROHS COMPLIANT: YES

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheetIPBD Datasheet+3
IPBD-08-D - IPBD-08-D

IPBD-08-D

Active
Samtec Inc.

CONNECTOR ROHS COMPLIANT: YES

Deep-Dive with AI

DocumentsDatasheetIPBD Datasheet+3

Technical Specifications

Parameters and characteristics for this part

SpecificationIPBD-08-D
Connector TypeReceptacle
Contact TerminationCrimp
Contact TypeFemale Socket
Fastening TypeLatch Lock
Insulation MaterialPolyamide (PA), Nylon
Mounting TypeFree Hanging (In-Line)
NoteContacts Not Included
Number of Positions16
Number of Rows2
Pitch [x]4.2 mm
Pitch [x]0.165 in
Row Spacing4.2 mm
Row Spacing0.165 in

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

DistributorPackageQuantity$
DigikeyBulk 1$ 2.74
10$ 2.09
25$ 1.88
50$ 1.74
100$ 1.61
250$ 1.46
500$ 1.36
1000$ 1.27
2500$ 1.16
NewarkEach 1$ 1.61
10$ 1.45
100$ 1.24
500$ 1.05
1000$ 0.89
2500$ 0.83
5000$ 0.79
10000$ 0.77

Description

General part information

IPBD-08 Series

16 Rectangular Connectors - Housings Receptacle 0.165" (4.20mm)
