Specification	PVS7F2HSS335M01

Actuator Marking	Power Symbol
Actuator Type	Round, Flush, Button
Circuit	DPDT
Color	Green
Color - Actuator/Cap	Silver
Current Rating	2 A
Electrical Life (Cycles)	50000
Illumination Type	LED
Illumination Voltage (Nominal)	24 V
Ingress Protection Description	Dust Tight, Water Resistant
Ingress Protection IP Rating	IP65
Mounting Type	Front, Panel Mount
Operating Temperature (Max)	55 °C
Operating Temperature (Min)	-20 °C
Panel Cutout Diameter	22 mm
Panel Cutout Shape	Circular
Quick Connect Size (0.110")	0.11 in
Switch Function	On-Mom
Termination Style	Quick Connect, Solder
Type	Illuminated, Anti-Vandal
Voltage Rating - DC	24 V

PVS7 Series

Part	Electrical Life (Cycles)	Voltage Rating - DC	Mounting Type	Current Rating	Type	Actuator Marking	Panel Cutout Diameter	Panel Cutout Shape	Circuit	Color - Actuator/Cap	Switch Function	Ingress Protection IP Rating	Ingress Protection Description	Actuator Type	Quick Connect Size (0.110")	Termination Style	Illumination Type	Color	Operating Temperature (Min)	Operating Temperature (Max)	Illumination Voltage (Nominal)
E-Switch PVS7F2GSS331	50000	24 V	Front Panel Mount	2 A	Anti-Vandal Illuminated	No Marking	22 mm	Circular	DPDT	Silver	On-On	IP65	Dust Tight Water Resistant	Button Flush Round	0.11 in	Quick Connect Solder	LED	Green	-20 °C	55 °C
E-Switch PVS7F2HSS335M01	50000	24 V	Front Panel Mount	2 A	Anti-Vandal Illuminated	Power Symbol	22 mm	Circular	DPDT	Silver	On-Mom	IP65	Dust Tight Water Resistant	Button Flush Round	0.11 in	Quick Connect Solder	LED	Green	-20 °C	55 °C	24 V
E-Switch PVS7F2HSS341	50000	24 V	Front Panel Mount	2 A	Anti-Vandal Illuminated	No Marking	22 mm	Circular	DPDT	Silver	On-Mom	IP65	Dust Tight Water Resistant	Button Flush Round	0.11 in	Quick Connect Solder	LED	Blue	-20 °C	55 °C
E-Switch PVS7F2GSS311	50000	24 V	Front Panel Mount	2 A	Anti-Vandal Illuminated	No Marking	22 mm	Circular	DPDT	Silver	On-On	IP65	Dust Tight Water Resistant	Button Flush Round	0.11 in	Quick Connect Solder	LED	Red	-20 °C	55 °C
E-Switch PVS7F2GSS341	50000	24 V	Front Panel Mount	2 A	Anti-Vandal Illuminated	No Marking	22 mm	Circular	DPDT	Silver	On-On	IP65	Dust Tight Water Resistant	Button Flush Round	0.11 in	Quick Connect Solder	LED	Blue	-20 °C	55 °C
E-Switch PVS7F2BSS335	50000	24 V	Front Panel Mount	2 A	Anti-Vandal Illuminated	No Marking	22 mm	Circular	SPDT	Silver	On-Mom	IP65	Dust Tight Water Resistant	Button Flush Round	0.11 in	Quick Connect Solder	LED	Green	-20 °C	55 °C	24 V
E-Switch PVS7F2HSS331	50000	24 V	Front Panel Mount	2 A	Anti-Vandal Illuminated	No Marking	22 mm	Circular	DPDT	Silver	On-Mom	IP65	Dust Tight Water Resistant	Button Flush Round	0.11 in	Quick Connect Solder	LED	Green	-20 °C	55 °C
E-Switch PVS7F2HSS331M01	50000	24 V	Front Panel Mount	2 A	Anti-Vandal Illuminated	Power Symbol	22 mm	Circular	DPDT	Silver	On-Mom	IP65	Dust Tight Water Resistant	Button Flush Round	0.11 in	Quick Connect Solder	LED	Green	-20 °C	55 °C
