SP600-54

Active

Bergquist

THERM PAD 19.05MMX12.7MM GREEN

Search across all available documentation for this part.

Active

Bergquist

THERM PAD 19.05MMX12.7MM GREEN

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Thermal Pad Green 19.05mm x 12.70mm Rectangular

Technical documentation and resources

Part	Color	Thermal Resistivity	Outline [x]	Outline [y]	Shape	Usage	Thickness	Thickness	Shelf Life Start	Shelf Life
Bergquist SP600-114	Green	0.35 °C/W	24 mm	21.01 mm	Rectangular	TO-218, TO-220, TO-247	0.229 mm	0.009 in
Bergquist SP600-105	Green	0.35 °C/W	36.83 mm	21.29 mm	Rectangular	SIP	0.229 mm	0.009 in	Date of Manufacture	12 Months
Bergquist SP600-54	Green	0.35 °C/W	19.05 mm	12.7 mm	Rectangular	TO-220	0.229 mm	0.009 in	Date of Manufacture	12 Months
Bergquist SP600-05	Green	0.35 °C/W	41.91 mm	28.96 mm	Rhombus	TO-3	0.229 mm	0.009 in	Date of Manufacture	12 Months
Bergquist SP600-02	Green	0.35 °C/W	45.21 mm	31.75 mm	Rhombus	TO-3	0.229 mm	0.009 in
