HTSS-108-01-T-D

Active

Samtec Inc.

CONN HEADER VERT 16POS 2.54MM

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsHTSS Datasheet Datasheet

HTSS-108-01-T-D

Active

Samtec Inc.

CONN HEADER VERT 16POS 2.54MM

Deep-Dive with AI

DocumentsHTSS Datasheet Datasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	HTSS-108-01-T-D

null

HTSS-108 Series

Part	Contact Length - Post	Contact Length - Post	Number of Rows	Shrouding	Mounting Type	Overall Contact Length	Overall Contact Length	Contact Finish - Mating	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Contact Material	Connector Type	Insulation Material	Fastening Type	Contact Shape	Termination	Pitch - Mating	Pitch - Mating	Style	Material Flammability Rating	Features	Number of Positions Loaded	Operating Temperature [Min]	Operating Temperature [Max]	Contact Type	Number of Positions	Contact Length - Mating	Contact Length - Mating	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Insulation Height [custom]	Insulation Height [custom]	Contact Finish - Post	Insulation Color	Number of Positions Loaded	Insulation Height	Insulation Height	Contact Finish Thickness - Post	Contact Finish Thickness - Post
Samtec Inc. HTSS-108-01-F-D-01	2.92 mm	0.115 in	2	Shrouded - 4 Wall	Through Hole	0.48 in	12.19 mm	Gold	2.54 mm	0.1 in	Phosphor Bronze	Header	Liquid Crystal Polymer (LCP)	Push-Pull	Square	Solder	0.1 in	2.54 mm	Board to Board Cable	UL94 V-0	Keying Slot	15	-55 °C	125 °C	Male Pin	16	6.35 mm	0.25 in	3 µin	0.076 µm	0.35 in	8.89 mm	Tin	Natural
Samtec Inc. HTSS-108-04-S-D-RA	3.3 mm	0.13 in	2	Shrouded - 4 Wall	Through Hole Right Angle			Gold	2.54 mm	0.1 in	Phosphor Bronze	Header	Liquid Crystal Polymer (LCP)	Push-Pull	Square	Solder	0.1 in	2.54 mm	Board to Board Cable	UL94 V-0	Keying Slot		-55 °C	125 °C	Male Pin	16	6.35 mm	0.25 in	30 Áin	0.76 Ám			Tin	Natural	All	0.365 in	9.27 mm
Samtec Inc. HTSS-108-01-S-D-EM			2	Shrouded - 4 Wall	Board Edge Straddle Mount			Gold	2.54 mm	0.1 in	Phosphor Bronze	Header	Liquid Crystal Polymer (LCP)	Push-Pull	Square	Solder	0.1 in	2.54 mm	Board to Board Cable	UL94 V-0	Keying Slot		-55 °C	125 °C	Male Pin	16	6.35 mm	0.25 in	30 Áin	0.76 Ám			Tin	Natural	All
Samtec Inc. HTSS-108-04-F-D-RA	3.3 mm	0.13 in	2	Shrouded - 4 Wall	Through Hole Right Angle			Gold	2.54 mm	0.1 in	Phosphor Bronze	Header	Liquid Crystal Polymer (LCP)	Push-Pull	Square	Solder	0.1 in	2.54 mm	Board to Board Cable	UL94 V-0	Keying Slot		-55 °C	125 °C	Male Pin	16	6.35 mm	0.25 in	3 µin	0.076 µm			Tin	Natural	All	0.365 in	9.27 mm
Samtec Inc. HTSS-108-01-S-DV			2	Shrouded - 4 Wall	Surface Mount			Gold	2.54 mm	0.1 in	Phosphor Bronze	Header	Liquid Crystal Polymer (LCP)	Push-Pull	Square	Solder	0.1 in	2.54 mm	Board to Board Cable	UL94 V-0	Keying Slot		-55 °C	125 °C	Male Pin	16	6.35 mm	0.25 in	30 Áin	0.76 Ám	0.35 in	8.89 mm	Tin	Natural	All
Samtec Inc. HTSS-108-01-L-DV-P			2	Shrouded - 4 Wall	Surface Mount			Gold	2.54 mm	0.1 in	Phosphor Bronze	Header	Liquid Crystal Polymer (LCP)	Push-Pull	Square	Solder	0.1 in	2.54 mm	Board to Board Cable	UL94 V-0	Keying Slot Pick and Place		-55 °C	125 °C	Male Pin	16	6.35 mm	0.25 in	10 çin	0.25 çm	0.35 in	8.89 mm	Tin	Natural	All
Samtec Inc. HTSS-108-01-H-D	2.92 mm	0.115 in	2	Shrouded - 4 Wall	Through Hole	0.48 in	12.19 mm	Gold	2.54 mm	0.1 in	Phosphor Bronze	Header	Liquid Crystal Polymer (LCP)	Push-Pull	Square	Solder	0.1 in	2.54 mm	Board to Board Cable	UL94 V-0	Keying Slot		-55 °C	125 °C	Male Pin	16	6.35 mm	0.25 in	30 Áin	0.76 Ám	0.35 in	8.89 mm	Gold	Natural	All			3 µin	0.076 µm
Samtec Inc. HTSS-108-01-SM-DV			2	Shrouded - 4 Wall	Surface Mount			Gold	2.54 mm	0.1 in	Phosphor Bronze	Header	Liquid Crystal Polymer (LCP)	Push-Pull	Square	Solder	0.1 in	2.54 mm	Board to Board Cable	UL94 V-0	Keying Slot		-55 °C	125 °C	Male Pin	16	6.35 mm	0.25 in	30 Áin	0.76 Ám	0.35 in	8.89 mm	Tin	Natural	All
Samtec Inc. HTSS-108-03-L-D
Samtec Inc. HTSS-108-01-T-D
