35616 0035000

Active

Belden Inc.

HOOK-UP STRND 16AWG ORANGE

Search across all available documentation for this part.

Active

Belden Inc.

HOOK-UP STRND 16AWG ORANGE

Technical Specifications

Parameters and characteristics for this part

Specification	35616 0035000

Cable Type	Hook-Up
Conductor Material	Copper, Tinned
Conductor Strand [custom]	30 AWG
Conductor Strand [custom]	26
Jacket (Insulation) Diameter	0.122 in
Jacket (Insulation) Diameter	3.1 mm
Jacket (Insulation) Material	Polyethylene (XLPE), Irradiated
Jacket (Insulation) Thickness	0.8 mm
Jacket (Insulation) Thickness	0.031 in
Jacket Color	Orange
Ratings	UL Style 3173
Voltage	600 V
Wire Gauge	16 AWG

Part	Jacket (Insulation) Diameter	Jacket (Insulation) Diameter	Cable Type	Jacket (Insulation) Material	Voltage	Conductor Material	Conductor Strand [custom]	Conductor Strand [custom]	Wire Gauge	Ratings	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Length [x]	Length [x]	Jacket Color
Belden Inc. 35616 009500	0.122 in	3.1 mm	Hook-Up	Polyethylene (XLPE) Irradiated	600 V	Copper Tinned	30 AWG	26	16 AWG	UL Style 3173	0.8 mm	0.031 in	500 '	152.4 m
Belden Inc. 35616 0035000	0.122 in	3.1 mm	Hook-Up	Polyethylene (XLPE) Irradiated	600 V	Copper Tinned	30 AWG	26	16 AWG	UL Style 3173	0.8 mm	0.031 in			Orange
Belden Inc. 35616 002500	0.122 in	3.1 mm	Hook-Up	Polyethylene (XLPE) Irradiated	600 V	Copper Tinned	30 AWG	26	16 AWG	UL Style 3173	0.76 mm	0.762 mm	100 ft	30.5 m	Red

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	5000	$ 0.69

General part information

16 AWG Hook-Up Wire 26/30 Orange 600V 5000' (1524.0m)

Technical documentation and resources
