Description

General part information

TPD2E001 Series

The TPD2E001 is a two-channel Transient Voltage Suppressor (TVS) based Electrostatic Discharge (ESD) protection diode array. The TPD2E001 is rated to dissipate ESD strikes at the maximum level specified in the IEC 61000-4-2 Level 4 international standard.

The DRS package (3.00 mm × 3.00 mm) is also available as a non-magnetic package for medical imaging applications.

See also TPD2E2U06DRLR which is p2p compatible to TPD2E001DRLR and offers higher IEC ESD Protection, lower clamping voltage, and eliminates the input capacitor requirement.

Technical Specifications

Parameters and characteristics for this part

SpecificationTPD2E001DRST-NM
ApplicationsEthernet
Mounting TypeSurface Mount
Operating Temperature (Max)85 °C
Operating Temperature (Min)-40 °C
Package / Case6-WDFN Exposed Pad
Package Length3 mm
Package Name6-SON
Package Width3 mm
Power Line ProtectionYes
TypeSteering (Rail to Rail)
Unidirectional Channels2
Voltage - Breakdown (Min)11 V
Voltage - Reverse Standoff (Max)5.5 V
