AF2GSDI-ZAFXM

Active

ATP Electronics, Inc.

MEMORY CARD SD 2GB CLASS 6 SLC

Search across all available documentation for this part.

Active

ATP Electronics, Inc.

MEMORY CARD SD 2GB CLASS 6 SLC

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Memory Card SD™ 2GB Class 6 SLC

Technical documentation and resources

Parameters and characteristics commom to parts in this series

Specification	AF2GSDI-ZAFXM	AF2G Series

Form Factor	-	Disk-On-Module, eUSB, Slim-SATA, Disk-On-Module, SATA DOM
Memory Size	2 GB	2 GB
Memory Type	SD™	Solid State Drive (SSD) FLASH - NAND (SLC), CompactFlash®, microSD™, CFast, FLASH - NAND (SLC), SD™
Operating Temperature [Max]	85 °C	85 °C
Operating Temperature [Min]	-40 °C	-40 °C
Size / Dimension	-	26.6 - 36.9 mm
Size / Dimension	-	4.5 - 11.5 mm
Size / Dimension	-	12 - 26.6 mm
Speed	Class 6	Class 6
Speed - Read	-	21 - 112 MB/s
Speed - Write	-	16 - 91 MB/s
Technology	SLC	SLC
Type	-	USB 2.0
Weight	-	8 g
Weight	-	0.282 oz

SSD 2GB EUSB SLC 5V

Part	Memory Size	Operating Temperature [Max]	Operating Temperature [Min]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Speed - Write	Memory Type	Speed - Read	Form Factor	Technology	Type	Weight	Weight	Speed
ATP Electronics, Inc. AF2GSSGH-AACXP	2 GB	85 °C	-40 °C	36.9 mm	11.5 mm	26.6 mm	27 MB/s	Solid State Drive (SSD) FLASH - NAND (SLC)	30 MB/s	Disk-On-Module, eUSB
ATP Electronics, Inc. AF2GCFI-TADXP	2 GB	85 °C	-40 °C					CompactFlash®			SLC
ATP Electronics, Inc. AF2GUDI-ZAFXM	2 GB	85 °C	-40 °C					microSD™			SLC
ATP Electronics, Inc. AF2GCSI-OEM	2 GB	85 °C	-40 °C					CFast			SLC
ATP Electronics, Inc. AF2GUFP3NC(I)-OEM	2 GB	85 °C	-40 °C	26.6 mm	4.5 mm	12 mm	16 MB/s	FLASH - NAND (SLC)	21 MB/s			USB 2.0	8 g	0.282 oz
ATP Electronics, Inc. AF2GSDI-ZAFXM	2 GB	85 °C	-40 °C					SD™			SLC				Class 6
ATP Electronics, Inc. AF2GSSGI-OEM	2 GB	85 °C	-40 °C	36.9 mm	11.5 mm	26.6 mm	27 MB/s	Solid State Drive (SSD) FLASH - NAND (SLC)	30 MB/s	Disk-On-Module, eUSB
ATP Electronics, Inc. AF2GSSEL-OEM	2 GB	85 °C	-40 °C				91 MB/s	Solid State Drive (SSD) FLASH - NAND (SLC)	112 MB/s	Slim-SATA
ATP Electronics, Inc. AF2GSSEI-OEM	2 GB	85 °C	-40 °C					Solid State Drive (SSD) FLASH - NAND (SLC)		Disk-On-Module, SATA DOM
ATP Electronics, Inc. AF2GUFEDBK(I)-OEM	2 GB	85 °C	-40 °C	33.7 mm	9.4 mm	17.5 mm	16 MB/s	FLASH - NAND (SLC)	21 MB/s			USB 2.0	8 g	0.282 oz
