MPT-02-01-01-L-RA-LC

Active

Samtec Inc.

-55℃~+125℃ GOLD COPPER ALLOY PLUGIN BUTTON AND STRIP BATTERY CONNECTOR ROHS

Search across all available documentation for this part.

Active

Samtec Inc.

-55℃~+125℃ GOLD COPPER ALLOY PLUGIN BUTTON AND STRIP BATTERY CONNECTOR ROHS

Technical Specifications

Parameters and characteristics for this part

Part	Pitch [x]	Pitch [x]	Color	Contact Finish	Number of Rows	Fastening Type	Number of Positions	Operating Temperature [Min]	Operating Temperature [Max]	Connector Type	Contact Finish Thickness	Contact Finish Thickness	Termination	Current Rating (Amps)	Features	Voltage Rating	Contact Material	Mounting Type	Material - Insulation
Samtec Inc. MPT-02-01-01-L-RA-LC	5 mm	0.197 in	Black	Gold	1	Locking Ramp	2	-55 °C	125 °C	Header Male Blades	10 Áin	0.25 Ám	Solder	30 A	Board Lock Flange	812 V	Copper Alloy	Through Hole Right Angle	Liquid Crystal Polymer (LCP)
Samtec Inc. MPT-02-01-01-T-RA-SD	5 mm	0.197 in	Black	Tin	1	Locking Ramp Screw Lock	2	-55 °C	105 ░C	Header Male Blades			Solder	30 A	Flange	812 V	Copper Alloy	Board Edge Right Angle Through Hole	Liquid Crystal Polymer (LCP)
Samtec Inc. MPT-02-6.30-03-L-V	5 mm	0.197 in	Black	Gold	1	Locking Ramp	2	-55 °C	125 °C	Header Male Blades	10 Áin	0.25 Ám	Solder	30 A	Board Guide Latch Lock	812 V	Copper Alloy	Through Hole	Liquid Crystal Polymer (LCP)
Samtec Inc. MPT-02-01-03-L-RA-SD	5 mm	0.197 in	Black	Gold	1	Locking Ramp Screw Lock	2	-55 °C	125 °C	Header Male Blades	10 Áin	0.25 Ám	Solder	30 A	Flange	812 V	Copper Alloy	Board Edge Right Angle Through Hole	Liquid Crystal Polymer (LCP)
Samtec Inc. MPT-02-6.30-01-L-V	5 mm	0.197 in	Black	Gold	2	Locking Ramp	2	-55 °C	125 °C	Header Male Blades	10 Áin	0.25 Ám	Solder	30 A	Board Guide Latch Lock	812 V	Copper Alloy	Through Hole	Liquid Crystal Polymer (LCP)

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

2 Position Header, Male Blades Connector Solder 0.197" (5.00mm) Through Hole, Right Angle
