STGIB10CH60TS-X
UnknownSTMicroelectronics
SLLIMM 2ND SERIES IPM, 3-PHASE I
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | STGIB10CH60TS-X |
|---|---|
| Configuration | 3 Phase Inverter |
| Current | 15 A |
| Mounting Type | Through Hole |
| Package / Case | 29.3 mm |
| Package / Case | 1.154 in |
| Package / Case | 26-PowerDIP Module |
| Package / Case [x] | 1.146 in |
| Package / Case [y] | 29.1 mm |
| Type | IGBT |
| Voltage | 600 V |
| Voltage - Isolation | 1500 VAC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 1 | $ 14.95 | |
| 10 | $ 13.17 | |||
| 156 | $ 11.39 | |||
| 624 | $ 10.32 | |||
Description
General part information
STGIB10 Series
Power Driver Module IGBT 3 Phase Inverter 600 V 15 A 26-PowerDIP Module (1.154", 29.30mm)
