B4505CS

Active

TE Connectivity Raychem Cable Protection

WHIP,MC,CC,450-470MHZ, TUN,5,CH,GP,SPRIN

Search across all available documentation for this part.

Active

TE Connectivity Raychem Cable Protection

WHIP,MC,CC,450-470MHZ, TUN,5,CH,GP,SPRIN

Technical Specifications

Parameters and characteristics for this part

Part	Accessory Type	Antenna Type	Height (Max)	Height (Max) [Max]	Frequency Range [Min]	Frequency Range [Max]	Termination	Frequency Group [Max]	Frequency Group [Min]	VSWR	Gain	Frequency (Center/Band)	Number of Bands	Mounting Type	Power - Max [Max]	Ingress Protection
TE Connectivity Raychem Cable Protection B4505CCO	Antenna Mounting Base
TE Connectivity Raychem Cable Protection B4505CS		Whip Straight	939.8 mm	37 in	450 MHz	470 MHz	NMO	1 GHz	300 MHz	2	5 dBi	460 MHz	1	Base Mount
TE Connectivity Raychem Cable Protection B4505CNS		Whip Straight	819.15 mm	32.25 in	450 MHz	470 MHz	NMO	1 GHz	300 MHz	2	5 dBi	460 MHz	1	Base Mount	100 W
TE Connectivity Raychem Cable Protection B4505CRO	Antenna Mounting Base
TE Connectivity Raychem Cable Protection B4505CNR		Whip Straight	819.15 mm	32.25 in	450 MHz	470 MHz	NMO	1 GHz	300 MHz		5 dBi	460 MHz	1	Base Mount	100 W	IP67
TE Connectivity Raychem Cable Protection B4505CS		Whip Straight	939.8 mm	37 in	450 MHz	470 MHz	NMO	1 GHz	300 MHz	2	5 dBi	460 MHz	1	Base Mount

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Whip Antenna, Single Band, UHF / Vehicular, External Mount, Stud/Screw/Lug Mount, NMO, Omnidirectional, Single Port, 3 < 6 dBi Peak Gain
