Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 16 | $ 62.72 | |
General part information
Solid State SPST-NO (1 Form A) x 2 Module
Technical documentation and resources
Parameters and characteristics commom to parts in this series
| Specification | ASR-SID240D50ZL-SP | ASR-SID Series |
|---|---|---|
| Approval Agency | cURus, CE, TUV | cURus, CE, TUV |
| Circuit | SPST-NO (1 Form A) x 2 | SPST-NO (1 Form A) x 2 |
| Load Current | 50 A | 25 - 50 A |
| Mounting Type | Chassis Mount | Chassis Mount |
| Operating Temperature [Max] | 80 C | 80 C |
| Operating Temperature [Min] | -30 ░C | -30 ░C |
| Output Type | AC, Zero Cross | AC, Zero Cross |
| Package / Case | Module | Module |
| Termination Style | Screw Terminal | Quick Connect - 0.250" (6.3mm), Screw Terminal |
| Voltage - Input [Max] | 15 V | 15 - 32 V |
| Voltage - Input [Min] | 4 V | 4 - 15 V |
| Voltage - Load [Max] | 280 V | 280 - 530 V |
| Voltage - Load [Min] | 24 V | 24 V |
SSR RELAY SPST-NO 40A 24-530V
| Part | Output Type | Circuit | Voltage - Input [Max] | Voltage - Input [Min] | Package / Case | Load Current | Mounting Type | Voltage - Load [Min] | Voltage - Load [Max] | Termination Style | Approval Agency | Operating Temperature [Min] | Operating Temperature [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Altran Magnetics, LLC ASR-SID480D40ZL | AC, Zero Cross | SPST-NO (1 Form A) x 2 | 15 V | 4 V | Module | 40 A | Chassis Mount | 24 V | 530 V | Quick Connect - 0.250" (6.3mm) | CE, cURus, TUV | -30 ░C | 80 C |
Altran Magnetics, LLC ASR-SID480D25ZH | AC, Zero Cross | SPST-NO (1 Form A) x 2 | 32 V | 15 V | Module | 25 A | Chassis Mount | 24 V | 530 V | Quick Connect - 0.250" (6.3mm) | CE, cURus, TUV | -30 ░C | 80 C |
Altran Magnetics, LLC ASR-SID480D25ZL-S | AC, Zero Cross | SPST-NO (1 Form A) x 2 | 15 V | 4 V | Module | 25 A | Chassis Mount | 24 V | 530 V | Screw Terminal | CE, cURus, TUV | -30 ░C | 80 C |
Altran Magnetics, LLC ASR-SID240D50ZL-SP | AC, Zero Cross | SPST-NO (1 Form A) x 2 | 15 V | 4 V | Module | 50 A | Chassis Mount | 24 V | 280 V | Screw Terminal | CE, cURus, TUV | -30 ░C | 80 C |
Altran Magnetics, LLC ASR-SID480D25ZL-C | AC, Zero Cross | SPST-NO (1 Form A) x 2 | 15 V | 4 V | Module | 25 A | Chassis Mount | 24 V | 530 V | Quick Connect - 0.250" (6.3mm) | CE, cURus, TUV | -30 ░C | 80 C |
Altran Magnetics, LLC ASR-SID240D25ZL | AC, Zero Cross | SPST-NO (1 Form A) x 2 | 15 V | 4 V | Module | 25 A | Chassis Mount | 24 V | 280 V | Quick Connect - 0.250" (6.3mm) | CE, cURus, TUV | -30 ░C | 80 C |
