805-10-021-00-006000

Active

Mill-Max Manufacturing Corp.

CONN SPRING TARGET 21POS PCB

Search across all available documentation for this part.

Active

Mill-Max Manufacturing Corp.

CONN SPRING TARGET 21POS PCB

Technical Specifications

Parameters and characteristics for this part

Part	Contact Finish Thickness	Contact Finish Thickness	Number of Rows	Number of Contacts	Row Spacing [x]	Row Spacing	Contact Finish	Connector Type	Mounting Type	Material	Pitch [x]	Pitch [x]
Mill-Max Manufacturing Corp. 805-10-009-00-006000	0.51 µm	20 µin	3	9	0.1 in	2.54 mm	Gold	Mating Target	Through Hole	Brass Alloy	2.54 mm	0.1 in
Mill-Max Manufacturing Corp. 805-10-012-00-006000	0.51 µm	20 µin	3	12	0.1 in	2.54 mm	Gold	Mating Target	Through Hole	Brass Alloy	2.54 mm	0.1 in
Mill-Max Manufacturing Corp. 805-10-021-00-006000	0.51 µm	20 µin	3	21	0.1 in	2.54 mm	Gold	Mating Target	Through Hole	Brass Alloy	2.54 mm	0.1 in

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

21 Position Spring Mating Target Connector Through Hole

Technical documentation and resources

No documents available
