FT0H105ZF

Active

KEMET

CAP, 1F, 5.5V, SUPER, RADIAL

Search across all available documentation for this part.

Active

KEMET

CAP, 1F, 5.5V, SUPER, RADIAL

Technical Specifications

Parameters and characteristics for this part

Specification	FT0H105ZF

Capacitance	1 F
ESR (Equivalent Series Resistance)	3.5 Ohm
Height - Seated (Max) [Max] [z]	13 mm
Height - Seated (Max) [Max] [z]	0.512 "
Lead Spacing	0.3 "
Lead Spacing	7.62 mm
Mounting Type	Through Hole
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	Radial, Can
Size / Dimension [diameter]	0.846 "
Size / Dimension [diameter]	21.5 mm
Termination	PC Pins
Tolerance [Max]	80 %
Tolerance [Min]	-20 %
Voltage - Rated	5.5 V

Part	Lead Spacing	Lead Spacing	Size / Dimension [diameter]	Size / Dimension [diameter]	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Rated	Package / Case	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Capacitance	Mounting Type	Tolerance [Max]	Tolerance [Min]	Termination	ESR (Equivalent Series Resistance)	Size / Dimension	Height - Seated (Max)	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]
KEMET FT0H105ZF	0.3 "	7.62 mm	0.846 "	21.5 mm	85 °C	-40 °C	5.5 V	Radial Can	13 mm	0.512 "	1 F	Through Hole	80 %	-20 %	PC Pins	3.5 Ohm
KEMET FT0H225ZF	0.4 in	10.16 mm	1.122 in		85 °C	-40 °C	5.5 V	Radial Can			2.2 F	Through Hole	80 %	-20 %	PC Pins	1.8 Ohm	28.5 mm	14 mm	0.551 "
KEMET FT0H335ZF	0.591 in	15 mm	1.437 in	36.5 mm	85 °C	-40 °C	5.5 V	Radial Can			3.3 F	Through Hole	80 %	-20 %	PC Pins	1 Ohm			0.591 "	15 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

1 F (EDLC) Supercapacitor 5.5 V Radial, Can 3.5Ohm @ 1kHz
