FT0H335ZF

Active

KEMET

CAP 3.3F -20% +80% 5.5V T/H

Search across all available documentation for this part.

Active

KEMET

CAP 3.3F -20% +80% 5.5V T/H

Technical Specifications

Parameters and characteristics for this part

Specification	FT0H335ZF

Capacitance	3.3 F
ESR (Equivalent Series Resistance)	1 Ohm
Height - Seated (Max) [Max]	15 mm
Height - Seated (Max) [Max]	0.591 "
Lead Spacing	15 mm
Lead Spacing	0.591 in
Mounting Type	Through Hole
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	Radial, Can
Size / Dimension [diameter]	1.437 in
Size / Dimension [diameter]	36.5 mm
Termination	PC Pins
Tolerance [Max]	80 %
Tolerance [Min]	-20 %
Voltage - Rated	5.5 V

Part	Lead Spacing	Lead Spacing	Size / Dimension [diameter]	Size / Dimension [diameter]	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Rated	Package / Case	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Capacitance	Mounting Type	Tolerance [Max]	Tolerance [Min]	Termination	ESR (Equivalent Series Resistance)	Size / Dimension	Height - Seated (Max)	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]
KEMET FT0H105ZF	0.3 "	7.62 mm	0.846 "	21.5 mm	85 °C	-40 °C	5.5 V	Radial Can	13 mm	0.512 "	1 F	Through Hole	80 %	-20 %	PC Pins	3.5 Ohm
KEMET FT0H225ZF	0.4 in	10.16 mm	1.122 in		85 °C	-40 °C	5.5 V	Radial Can			2.2 F	Through Hole	80 %	-20 %	PC Pins	1.8 Ohm	28.5 mm	14 mm	0.551 "
KEMET FT0H335ZF	0.591 in	15 mm	1.437 in	36.5 mm	85 °C	-40 °C	5.5 V	Radial Can			3.3 F	Through Hole	80 %	-20 %	PC Pins	1 Ohm			0.591 "	15 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

3.3 F (EDLC) Supercapacitor 5.5 V Radial, Can 1Ohm @ 1kHz
