164A16709X

Active

Amphenol CONEC

CONN D-SUB RCPT 50POS VERT SLDR

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

164A16709X

Active

Amphenol CONEC

CONN D-SUB RCPT 50POS VERT SLDR

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	164A16709X

Color	Black
Connector Style	D-Sub
Connector Type	Receptacle, Female Sockets
Contact Finish	Gold
Contact Finish Thickness	Flash
Contact Material	Copper Alloy
Contact Type	Signal
Current Rating (Amps)	7.5 A
Dielectric Material	Polybutylene Terephthalate (PBT), Glass Filled
Flange Feature	4-40
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Positions	50
Number of Rows	3
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Shell Size, Connector Layout	5
Termination	Solder
Voltage Rating	125 VDC

164A167 Series

Part	Material Flammability Rating	Number of Positions	Backset Spacing [x]	Backset Spacing [x]	Operating Temperature [Min]	Operating Temperature [Max]	Contact Finish	Color	Current Rating (Amps)	Contact Type	Dielectric Material	Features	Mounting Type	Connector Style	Contact Finish Thickness	Contact Finish Thickness	Voltage Rating	Number of Rows	Connector Type	Flange Feature	Termination	Contact Material	Shell Size, Connector Layout	Shell Size, Connector Layout [custom]	Shell Size, Connector Layout [custom]	Flange Feature [custom]	Flange Feature [custom]	Shell Size, Connector Layout	Contact Finish Thickness
Amphenol CONEC 164A16799X	UL94 V-0	37	9.31 mm	0.367 in	-55 °C	125 °C	Gold	Black	7.5 A	Signal	Polybutylene Terephthalate (PBT) Glass Filled	Board Lock Mounting Brackets	Board Edge Right Angle Through Hole	D-Sub	8 çin	0.203 çm	125 VDC	2	Receptacle Female Sockets	Housing/Shell (4-40)	Solder	Copper Alloy	4 (DC C)
Amphenol CONEC 164A16719X	UL94 V-0	9			-55 °C	125 °C	Gold	Black	7.5 A	Signal	Polybutylene Terephthalate (PBT) Glass Filled		Through Hole	D-Sub	8 çin	0.203 çm	125 VDC	2	Receptacle Female Sockets		Solder	Copper Alloy		DE E	1	M3	M3
Amphenol CONEC 164A16749X	UL94 V-0	37			-55 °C	125 °C	Gold	Black	7.5 A	Signal	Polybutylene Terephthalate (PBT) Glass Filled		Through Hole	D-Sub	8 çin	0.203 çm	125 VDC	2	Receptacle Female Sockets		Solder	Copper Alloy	4 (DC C)			M3	M3
Amphenol CONEC 164A16709X	UL94 V-0	50			-55 °C	125 °C	Gold	Black	7.5 A	Signal	Polybutylene Terephthalate (PBT) Glass Filled		Through Hole	D-Sub			125 VDC	3	Receptacle Female Sockets	4-40	Solder	Copper Alloy						5	Flash
Amphenol CONEC 164A16739X	UL94 V-0				-55 °C	125 °C	Gold	Black	7.5 A	Signal	Polybutylene Terephthalate (PBT) Glass Filled		Through Hole	D-Sub	8 çin	0.203 çm	125 VDC	2	Receptacle Female Sockets		Solder	Copper Alloy		B DB	3	M3	M3
Amphenol CONEC 164A16769X	UL94 V-0	9	9.31 mm	0.367 in	-55 °C	125 °C	Gold	Black	7.5 A	Signal	Polybutylene Terephthalate (PBT) Glass Filled	Board Lock Mounting Brackets	Board Edge Right Angle Through Hole	D-Sub	8 çin	0.203 çm	125 VDC	2	Receptacle Female Sockets	Housing/Shell (4-40)	Solder	Copper Alloy		DE E	1
Amphenol CONEC 164A16729X	UL94 V-0	15			-55 °C	125 °C	Gold	Black	7.5 A	Signal	Polybutylene Terephthalate (PBT) Glass Filled		Through Hole	D-Sub	8 çin	0.203 çm	125 VDC	2	Receptacle Female Sockets		Solder	Copper Alloy				M3	M3	2

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 20.49
		10	$ 17.76
		25	$ 16.83
		50	$ 16.59
		100	$ 14.63
		250	$ 13.66
		500	$ 13.37

Description

General part information

164A167 Series

50 Position D-Sub Receptacle, Female Sockets Connector
