| 2 Wire Leads | 4000 RPM | Tubeaxial | 42.3 Pa | 0.17 in H2O | Polybutylene Terephthalate (PBT) | 5 V | 36 dB | CE, cUL, TUV, UL | Ball | Thermal Overload Protector (TOP) | 80 mm | 80 mm | 15.3 mm | 1.04 mł/min | 37 CFM | 0.128 lb | 58.06 g | | |
| 3 Wire Leads | 2800 RPM | Tubeaxial | 22.4 Pa | 0.09 in H2O | Polybutylene Terephthalate (PBT) | 12 VDC | 28 dB | CE, cUL, TUV, UL | Ball | Speed Sensor (Tach), Thermal Overload Protector (TOP) | 80 mm | 80 mm | 15.3 mm | 0.728 m³/min | 26 CFM | 0.128 lb | 58.06 g | 100 mA | |
| 2 Wire Leads | 4800 RPM | Tubeaxial | 57.3 Pa | 0.23 in H2O | Polybutylene Terephthalate (PBT) | 12 VDC | 40 dB(A) | CE, cUL, TUV, UL | Ball | Thermal Overload Protector (TOP) | 80 mm | 80 mm | 15.3 mm | 1.2 m³/min | 43 CFM | 0.128 lb | 58.06 g | 0.35 A | IP57 - Dust Protected, Waterproof |
| 4 Wire Leads | 3200 RPM | Tubeaxial | 27.4 Pa | 0.11 in H2O | Polybutylene Terephthalate (PBT) | 12 VDC | 31 dB(A) | CE, cUL, TUV, UL | Ball | Alarm Sensor, Locked Rotor Sensor, Thermal Overload Protector (TOP) | 80 mm | 80 mm | 15.3 mm | 0.812 mł/min | 29 CFM | 0.128 lb | 58.06 g | | |
| 3 Wire Leads | 4800 RPM | Tubeaxial | 57.3 Pa | 0.23 in H2O | Polybutylene Terephthalate (PBT) | 24 VDC | 40 dB(A) | CE, cUL, TUV, UL | Ball | Speed Sensor (Tach), Thermal Overload Protector (TOP) | 80 mm | 80 mm | 15.3 mm | 1.2 m³/min | 43 CFM | 0.128 lb | 58.06 g | 0.25 A | |
| 2 Wire Leads | 4800 RPM | Tubeaxial | 57.3 Pa | 0.23 in H2O | Polybutylene Terephthalate (PBT) | 12 VDC | 40 dB(A) | CE, cUL, TUV, UL | Ball | Thermal Overload Protector (TOP) | 80 mm | 80 mm | 15.3 mm | 1.2 m³/min | 43 CFM | 0.128 lb | 58.06 g | 0.35 A | |
| 2 Wire Leads | 3600 RPM | Tubeaxial | 34.9 Pa | 0.14 in H2O | Polybutylene Terephthalate (PBT) | 24 VDC | 34 dB(A) | CE, cUL, TUV, UL | Ball | Thermal Overload Protector (TOP) | 80 mm | 80 mm | 15.3 mm | 0.896 m³/min | 32 CFM | 0.128 lb | 58.06 g | 120 mA | |
| 3 Wire Leads | 4800 RPM | Tubeaxial | 57.3 Pa | 0.23 in H2O | Polybutylene Terephthalate (PBT) | 12 VDC | 40 dB(A) | CE, cUL, TUV, UL | Ball | Speed Sensor (Tach), Thermal Overload Protector (TOP) | 80 mm | 80 mm | 15.3 mm | 1.2 m³/min | 43 CFM | 0.128 lb | 58.06 g | 0.35 A | |
| 2 Wire Leads | 2800 RPM | Tubeaxial | 22.4 Pa | 0.09 in H2O | Polybutylene Terephthalate (PBT) | 12 VDC | 28 dB | CE, cUL, TUV, UL | Ball | Thermal Overload Protector (TOP) | 80 mm | 80 mm | 15.3 mm | 0.728 m³/min | 26 CFM | 0.128 lb | 58.06 g | 100 mA | |
| 2 Wire Leads | 2800 RPM | Tubeaxial | 22.4 Pa | 0.09 in H2O | Polybutylene Terephthalate (PBT) | 24 VDC | 28 dB | CE, cUL, TUV, UL | Ball | Thermal Overload Protector (TOP) | 80 mm | 80 mm | 15.3 mm | 0.728 m³/min | 26 CFM | 0.128 lb | 58.06 g | | |
