Description
General part information
MP0012 Series
Pushbutton Switch SPST-NO Standard Panel Mount, Front
Technical Specifications
Parameters and characteristics for this part
| Specification | MP0012/1/RD |
|---|---|
| Actuator Marking | No Marking |
| Actuator Type | Round, Flush, Button |
| Circuit | SPST-NO |
| Color - Actuator/Cap | Red |
| Current Rating | 1 A, 2 A |
| Mounting Type | Front, Panel Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -20 °C |
| Panel Cutout Diameter | 19.2 mm |
| Panel Cutout Shape | Circular |
| Switch Function | Off-Mom |
| Termination Style | Screw Terminal |
| Type | Standard |
| Voltage Rating - AC | 110 V |
| Voltage Rating - DC | 12 V |
