EG95EXGA-128-SGNS

Active

Quectel

RF TXRX MOD CELL NAV SMD

EG95EXGA-128-SGNS

Active

Quectel

RF TXRX MOD CELL NAV SMD

Description Specifications Series Pricing CAD Documents

Description

General part information

EG95 Series

Cellular, Navigation BeiDou, EDGE, Galileo, GLONASS, GPS, GNSS, GPRS, GSM, HSPA+, LTE, UMTS, WCDMA Transceiver Module Antenna Not Included Surface Mount

Technical Specifications

Parameters and characteristics for this part

Specification	EG95EXGA-128-SGNS

Antenna Type	Antenna Not Included
Current - Receiving	31 mA
Current - Transmitting	31 mA
Data Rate	150 MHz
Mounting Type	Surface Mount
Operating Temperature (Max)	75 °C
Operating Temperature (Min)	-35 °C
Package / Case	Module
Protocol	GSM, GPS, Galileo, LTE, WCDMA, UMTS, GPRS, EDGE, HSPA+, GNSS, BeiDou, GLONASS
RF Family/Standard	Navigation, Cellular
Serial Interfaces	SPI, UART, USB, I2C, PCM
Utilized IC / Part	MDM9207-0
Voltage - Supply (Maximum)	4.3 V
Voltage - Supply (Minimum)	3.3 V

EG95 Series

Part	Protocol	Data Rate	Serial Interfaces	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Operating Temperature (Max)	Operating Temperature (Min)	Current - Transmitting	RF Family/Standard	Antenna Type	Mounting Type	Package / Case	Current - Receiving	Utilized IC / Part
Quectel EG95EFBTEA-512-SNND	EDGE GPRS HSPA+ LTE UMTS WCDMA	150 MHz	I2C PCM SPI UART USB	4.3 V	3.3 V	75 °C	-35 °C	31 mA	Cellular	Antenna Not Included	Surface Mount	Module	31 mA
Quectel EG95NAFB-512-SGNS	BeiDou Galileo GLONASS GNSS GPRS GPS HSPA+ LTE UMTS WCDMA	150 MHz	I2C PCM SPI UART USB	4.3 V	3.3 V	75 °C	-35 °C	31 mA	Cellular Navigation	Antenna Not Included	Surface Mount	Module	31 mA	MDM9207-0
Quectel EG95NAFBTEA-512-SGNS	BeiDou Galileo GLONASS GNSS GPRS GPS HSPA+ LTE UMTS WCDMA	150 MHz	I2C PCM SPI UART USB	4.3 V	3.3 V	75 °C	-35 °C	31 mA	Cellular Navigation	Antenna Not Included	Surface Mount	Module	31 mA
Quectel EG95EFB-512-SNND	EDGE GPRS HSPA+ LTE UMTS WCDMA	150 MHz	I2C PCM SPI UART USB	4.3 V	3.3 V	75 °C	-35 °C	31 mA	Cellular	Antenna Not Included	Surface Mount	Module	31 mA	MDM9207-0
Quectel EG95EXGA-128-SGNS	BeiDou EDGE Galileo GLONASS GNSS GPRS GPS GSM HSPA+ LTE UMTS WCDMA	150 MHz	I2C PCM SPI UART USB	4.3 V	3.3 V	75 °C	-35 °C	31 mA	Cellular Navigation	Antenna Not Included	Surface Mount	Module	31 mA	MDM9207-0
Quectel EG95NAXGA-128-SGNS	BeiDou Galileo GLONASS GNSS GPRS GPS HSPA+ LTE UMTS WCDMA	150 MHz	I2C PCM SPI UART USB	4.3 V	3.3 V	75 °C	-35 °C	31 mA	Cellular Navigation	Antenna Not Included	Surface Mount	Module	31 mA	MDM9207-0

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

EG95EXGA-128-SGNS | Datasheet
