R41BI268050T0K

Active

KEMET

SAFETY CAPACITOR, METALLIZED PP, RADIAL BOX - 2 PIN, 0.068 ΜF, ± 10%, X1 / Y2, THROUGH HOLE

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsKEM_F3127_R41B_Y2_350.pdf Datasheet +2

R41BI268050T0K

Active

KEMET

SAFETY CAPACITOR, METALLIZED PP, RADIAL BOX - 2 PIN, 0.068 ΜF, ± 10%, X1 / Y2, THROUGH HOLE

Deep-Dive with AI

DocumentsKEM_F3127_R41B_Y2_350.pdf Datasheet +2

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	R41BI268050T0K

Applications	EMI, RFI Suppression, Automotive
Capacitance	0.068 µF
Dielectric Material	Metallized, Polypropylene (PP)
Lead Spacing	15 mm
Lead Spacing	0.591 in
Mounting Type	Through Hole
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-40 °C
Package / Case	Radial
Ratings	Y2, AEC-Q200, X1
Size / Dimension [x]	0.709 ", 18 mm
Size / Dimension [y]	0.433 in, 11 mm
Termination	PC Pins
Tolerance	10 %
Voltage Rating - AC	350 V
Voltage Rating - DC	1.5 kVDC
Voltage Rating - DC	1.5 kV

R413I Series

Part	Mounting Type	Capacitance	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Termination	Voltage Rating - DC	Voltage Rating - DC	Dielectric Material	Package / Case	Ratings	Applications	Operating Temperature [Max]	Operating Temperature [Min]	Tolerance	Lead Spacing	Lead Spacing	Voltage Rating - AC	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]
KEMET R413I222050T0K	Through Hole	0.022 µF	7.5 mm	18 mm	0.295 in	0.709 in	PC Pins	1.5 kVDC	1.5 kV	Metallized Polypropylene (PP)	Radial	AEC-Q200 X1 Y2	Automotive EMI RFI Suppression	125 °C	-40 °C	10 %	15 mm	0.591 in	300 V
KEMET R413I233000M1K	Through Hole	0.033 çF	7.5 mm	18 mm	0.295 in	0.709 in	PC Pins	1 kVDC	1 kV	Metallized Polypropylene (PP)	Radial	AEC-Q200 X1 Y2	Automotive EMI RFI Suppression	110 °C	-40 °C	10 %	15 mm	0.591 in	300 V
KEMET R413I14704000M	Through Hole	4700 pF	5 mm	18 mm	0.197 "	0.709 in	PC Pins	1 kVDC	1 kV	Metallized Polypropylene (PP)	Radial	AEC-Q200 X1 Y2	Automotive EMI RFI Suppression	110 °C	-40 °C	20 %	15 mm	0.591 in	300 V	0.437 in	11.1 mm
KEMET R413I2100CK00K	Through Hole	10000 pF	5 mm	18 mm	0.197 "	0.709 in	PC Pins	1 kVDC	1 kV	Metallized Polypropylene (PP)	Radial	AEC-Q200 X1 Y2	Automotive EMI RFI Suppression	110 °C	-40 °C	10 %	15 mm	0.591 in	300 V	0.437 in	11.1 mm
KEMET R41BI268050T0K	Through Hole	0.068 µF	0.433 in 11 mm	0.709 " 18 mm			PC Pins	1.5 kVDC	1.5 kV	Metallized Polypropylene (PP)	Radial	AEC-Q200 X1 Y2	Automotive EMI RFI Suppression	125 °C	-40 °C	10 %	15 mm	0.591 in	350 V
KEMET R413I21005000K	Through Hole	10000 pF	5 mm	18 mm	0.197 "	0.709 in	PC Pins	1 kVDC	1 kV	Metallized Polypropylene (PP)	Radial	AEC-Q200 X1 Y2	Automotive EMI RFI Suppression	110 °C	-40 °C	10 %	15 mm	0.591 in	300 V	0.437 in	11.1 mm
KEMET R413I24704000M	Through Hole		8.5 mm	18 mm	0.335 in	0.709 in	PC Pins	1 kVDC	1 kV	Metallized Polypropylene (PP)	Radial	AEC-Q200 X1 Y2	Automotive EMI RFI Suppression	110 °C	-40 °C	20 %	15 mm	0.591 in	300 V			0.571 in	14.5 mm
KEMET R413I2470JU00M	Through Hole		8.5 mm	18 mm	0.335 in	0.709 in	PC Pins	1 kVDC	1 kV	Metallized Polypropylene (PP)	Radial	AEC-Q200 X1 Y2	Automotive EMI RFI Suppression	110 °C	-40 °C	20 %	15 mm	0.591 in	300 V			0.571 in	14.5 mm
KEMET R413I147050T0K	Through Hole	4700 pF	5 mm	18 mm	0.197 "	0.709 in	PC Pins	1.5 kVDC	1.5 kV	Metallized Polypropylene (PP)	Radial	AEC-Q200 X1 Y2	Automotive EMI RFI Suppression	125 °C	-40 °C	10 %	15 mm	0.591 in	300 V	0.437 in	11.1 mm
KEMET R413I14700000M	Through Hole	4700 pF	5 mm	18 mm	0.197 "	0.709 in	PC Pins	1 kVDC	1 kV	Metallized Polypropylene (PP)	Radial	AEC-Q200 X1 Y2	Automotive EMI RFI Suppression	110 °C	-40 °C	20 %	15 mm	0.591 in	300 V	0.437 in	11.1 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 1.14
		10	$ 0.85
		50	$ 0.78
		350	$ 0.60
		700	$ 0.51
		1050	$ 0.45
		2800	$ 0.42
		5250	$ 0.40
TME	N/A	350	$ 0.80
		700	$ 0.75

Description

General part information

R413I Series

R41B series capacitors are THB Grade IIIB, Class X1/Y2, 350VAC, 125°C (automotive grade) metallized polypropylene film EMI suppression capacitors. R41B is constructed of metallized polypropylene film, encapsulated with self-extinguishing resin, in a box of material meeting the requirements of UL 94 V-0. Automotive Grade devices meet the demanding Automotive Electronics Council's AEC–Q200 qualification requirements. Suitable for use in electromagnetic interference (EMI) suppression filter in line-to-ground and across-the-line applications, requiring Y2/X1 safety classification. Suitable for use in situations where failure of the capacitor could lead to danger of electric shock.

Documents

Technical documentation and resources

KEM_F3127_R41B_Y2_350.pdf

Datasheet

R41BI268050T0K

Manufacturer Catalogue EN

Datasheet
