8458 060500 - MFG_8458-060500

8458 060500

Active
Belden Inc.

MULTICONDUCTOR CABLE, AUDIO CONTROL, UNSHIELDED, 15 CONDUCTOR, 22 AWG, 500 FT, 152.4 M

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheetCabling Solutions for Industrial Applications+1
8458 060500 - MFG_8458-060500

8458 060500

Active
Belden Inc.

MULTICONDUCTOR CABLE, AUDIO CONTROL, UNSHIELDED, 15 CONDUCTOR, 22 AWG, 500 FT, 152.4 M

Deep-Dive with AI

DocumentsDatasheetCabling Solutions for Industrial Applications+1

Technical Specifications

Parameters and characteristics for this part

Specification8458 060500
Cable TypeMulti-Conductor
Conductor InsulationPoly-Vinyl Chloride (PVC)
Conductor MaterialCopper, Tinned
Conductor Strand [custom]7
Conductor Strand [custom]30 AWG
Jacket (Insulation) MaterialPoly-Vinyl Chloride (PVC)
Jacket (Insulation) Thickness0.04 in
Jacket (Insulation) Thickness1.016 mm
Jacket ColorChrome
Length15.24 m
Length [x]50 ft, 500 '
Length [x]152.4 m
Number of Conductors15
Operating Temperature [Max]80 C
Operating Temperature [Min]-20 C
UsageAudio, Instrumentation, Control
Wire Gauge22 AWG

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

DistributorPackageQuantity$
DigikeyBulk 1$ 514.48
5$ 420.93
10$ 327.39
25$ 280.62
Spool 500$ 5.36
1000$ 5.09
1500$ 4.94
NewarkSpool of 500 1$ 3321.44
5$ 3192.99
10$ 3082.89

Description

General part information

8458 Series

The 8458 060500 is a 152.4m 15-core chrome Unshielded Multiconductor Cable for use with the audio, control and instrumentation. It has stranded tinned copper conductors, PVC insulation and jacket.
