TWR-5/3000-15/500-D12A-C
ActiveISOLATED BOARD MOUNT DC/DC CONVERTER, ITE, 3 OUTPUT, 20 W, 5 V, 3 A, +/-15 V
Deep-Dive with AI
Search across all available documentation for this part.
TWR-5/3000-15/500-D12A-C
ActiveISOLATED BOARD MOUNT DC/DC CONVERTER, ITE, 3 OUTPUT, 20 W, 5 V, 3 A, +/-15 V
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | TWR-5/3000-15/500-D12A-C | TWR-5 Series |
|---|---|---|
| Applications | - | ITE (Commercial) |
| Current - Output (Max) | - | 1 - 500 A |
| Current - Output (Max) | - | 210 mA |
| Current - Output (Max) | - | 210 mA |
| Efficiency | - | 84 % |
| Mounting Type | - | Through Hole |
| null | - | |
| Number of Outputs | - | 3 |
| Operating Temperature | - | 100 °C |
| Operating Temperature | - | -40 °C |
| Package / Case | - | 8-DIP Module, 7 Leads, 7-DIP Module, 6 Leads |
| Power (Watts) | - | 10 - 20 W |
| Size / Dimension | - | 50.8 mm |
| Size / Dimension | - | 2 in |
| Size / Dimension | - | 0.38 - 0.45 " |
| Size / Dimension | - | 2 - 25.4 in |
| Size / Dimension | - | 25.4 - 50.8 mm |
| Size / Dimension | - | 9.7 - 11.4 mm |
| Type | - | Isolated Module |
| Voltage - Input (Max) | - | 18 - 36 V |
| Voltage - Input (Min) | - | 9 V |
| Voltage - Isolation | - | 1.5 kV |
| Voltage - Output 1 | - | 5 V |
| Voltage - Output 2 | - | 12 - 15 V |
| Voltage - Output 3 | - | -15 - -12 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
TWR-5 Series
ISOLATED BOARD MOUNT DC/DC CONVERTER, ITE, 3 OUTPUT, 20 W, 5 V, 3 A, +/-15 V
| Part | Number of Outputs | Voltage - Input (Max) [Max] | Voltage - Output 2 | Applications | Voltage - Isolation | Current - Output (Max) | Voltage - Input (Min) [Min] | Operating Temperature [Max] | Operating Temperature [Min] | Power (Watts) | Package / Case | Voltage - Output 1 | Voltage - Output 3 | Type | Mounting Type | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [z] | Efficiency | Current - Output (Max) | Current - Output (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Murata Power Solutions Inc. TWR-5/3000-15/500-D12A-C | 3 | 36 V | 15 V | ITE (Commercial) | 1.5 kV | 3 A, 500 mA | 9 V | 100 °C | -40 °C | 20 W | 8-DIP Module, 7 Leads | 5 V | -15 V | Isolated Module | Through Hole | 50.8 mm | 2 in | 0.45 " | 2 in | 50.8 mm | 11.4 mm | |||
Murata Power Solutions Inc. TWR-5/3000-15/500-D12A-C | ||||||||||||||||||||||||
Murata Power Solutions Inc. TWR-5/1000-12/210-D12A-C | 3 | 18 V | 12 V | ITE (Commercial) | 1.5 kV | 1 A | 9 V | 100 °C | -40 °C | 10 W | 7-DIP Module, 6 Leads | 5 V | -12 V | Isolated Module | Through Hole | 50.8 mm | 2 in | 0.38 in | 25.4 mm | 25.4 mm | 9.7 mm | 84 % | 210 mA | 210 mA |
Description
General part information
TWR-5 Series
The TWR-5/3000-15/500-D12A-C is a 3-output board-mount fully-isolated DC to DC Converter with outstanding long-term high-reliability. The TWR A-series 20W 2 x 2-inch device is distinguished by its unique "power-sharing" architecture. It delivers any combination of primary plus auxiliary power as long as the total output power does not exceed 20W. This feature enables designers to select a single device to fulfill any number of different requirements. Its design combines straightforward circuit topologies, the newest components, proven SMT-on-PCB construction methods and highly repeatable automatic-assembly techniques. The superior durability is substantiated by a rigorous in-house qualification program that includes HALT (Highly Accelerated Life Testing). These full-featured triples have non-latching output current limiting, input overvoltage shutdown, input reverse-polarity protection and output overvoltage clamping to protect both the power converters and their loads.
