9975 0021000

Active

Belden Inc.

HOOK-UP SOLID 24AWG RED

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet Cabling Solutions for Industrial Applications

9975 0021000

Active

Belden Inc.

HOOK-UP SOLID 24AWG RED

Deep-Dive with AI

DocumentsDatasheet Cabling Solutions for Industrial Applications

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	9975 0021000

Cable Type	Hook-Up
Conductor Material	Copper, Tinned
Conductor Strand	Solid
Jacket (Insulation) Diameter [diameter]	0.04 in
Jacket (Insulation) Diameter [diameter]	1.02 mm
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket (Insulation) Thickness	0.25 mm
Jacket (Insulation) Thickness	0.01 in
Jacket Color	Red
Length	1000 ft
Length	304.8 m
Length [x]	500 '
Length [x]	152.4 m
Operating Temperature [Max]	80 C
Operating Temperature [Min]	-20 C
Ratings	UL Style 1061
Voltage	300 V
Wire Gauge	24 AWG

9975 Series

Part	Voltage	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Length	Length	Wire Gauge	Conductor Strand	Cable Type	Ratings	Operating Temperature [Min]	Operating Temperature [Max]	Jacket Color	Jacket (Insulation) Material	Conductor Material	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Length [x]	Length [x]
Belden Inc. 9975 0081000	300 V	0.04 in	1.02 mm	1000 ft	304.8 m	24 AWG	Solid	Hook-Up	UL Style 1061	-20 C	80 C	Gray	Poly-Vinyl Chloride (PVC)	Copper Tinned	0.25 mm	0.01 in
Belden Inc. 9975 0101000	300 V	0.04 in	1.02 mm	1000 ft	304.8 m	24 AWG	Solid	Hook-Up	UL Style 1061	-20 C	80 C	Black	Poly-Vinyl Chloride (PVC)	Copper Tinned	0.25 mm	0.01 in
Belden Inc. 9975 0041000	300 V	0.04 in	1.02 mm	1000 ft	304.8 m	24 AWG	Solid	Hook-Up	UL Style 1061	-20 C	80 C	Yellow	Poly-Vinyl Chloride (PVC)	Copper Tinned	0.25 mm	0.01 in
Belden Inc. 9975 002100	300 V	0.04 in	1.02 mm			24 AWG	Solid	Hook-Up	UL Style 1061	-20 C	80 C	Red	Poly-Vinyl Chloride (PVC)	Copper Tinned	0.25 mm	0.01 in	30.5 m	100 ft
Belden Inc. 9975 0021000	300 V	0.04 in	1.02 mm	1000 ft	304.8 m	24 AWG	Solid	Hook-Up	UL Style 1061	-20 C	80 C	Red	Poly-Vinyl Chloride (PVC)	Copper Tinned	0.25 mm	0.01 in	152.4 m	500 '
Belden Inc. 9975 0031000	300 V	0.04 in	1.02 mm	1000 ft	304.8 m	24 AWG	Solid	Hook-Up	UL Style 1061	-20 C	80 C	Orange	Poly-Vinyl Chloride (PVC)	Copper Tinned	0.25 mm	0.01 in
Belden Inc. 9975 0051000	300 V	0.04 in	1.02 mm	1000 ft	304.8 m	24 AWG	Solid	Hook-Up	UL Style 1061	-20 C	80 C	Green	Poly-Vinyl Chloride (PVC)	Copper Tinned	0.25 mm	0.01 in
Belden Inc. 9975 0091000	300 V	0.04 in	1.02 mm	1000 ft	304.8 m	24 AWG	Solid	Hook-Up	UL Style 1061	-20 C	80 C		Poly-Vinyl Chloride (PVC)	Copper Tinned	0.25 mm	0.01 in

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 351.76
		5	$ 287.81
		10	$ 223.85
		25	$ 191.87
		50	$ 179.08
	Spool	1000	$ 0.39

Description

General part information

9975 Series

24 AWG Hook-Up Wire Solid Red 300V 1000.0' (304.8m)

Documents

Technical documentation and resources

Datasheet

Cabling Solutions for Industrial Applications

Datasheet
