9975 0101000

Unknown

HOOK-UP SOLID 24AWG BLACK

Unknown

HOOK-UP SOLID 24AWG BLACK

Description

General part information

24 AWG Hook-Up Wire Solid Black 300V 1000.0' (304.8m)

Parameters and characteristics for this part

Specification	9975 0101000

Cable Type	Hook-Up
Conductor Material	Tinned, Copper
Conductor Strand	Solid
Jacket (Insulation) Diameter	0.04 in
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket (Insulation) Thickness	0.01 in
Jacket Color	Black
Length	500 ft, 1000 ft, 50 ft
Operating Temperature (Max)	80 °C
Operating Temperature (Min)	-20 °C
Ratings	Style, 1061, UL
Voltage	300 V
Wire Gauge	24 AWG

Part	Cable Type	Jacket (Insulation) Diameter	Voltage	Conductor Material	Jacket Color	Wire Gauge	Ratings	Operating Temperature (Min)	Operating Temperature (Max)	Conductor Strand	Length	Jacket (Insulation) Thickness	Jacket (Insulation) Material
Belden Inc. 9975 0081000	Hook-Up	0.04 in	300 V	Copper Tinned	Gray	24 AWG	1061 Style UL	-20 °C	80 °C	Solid	1000 ft	0.01 in	Poly-Vinyl Chloride (PVC)
Belden Inc. 9975 0101000	Hook-Up	0.04 in	300 V	Copper Tinned	Black	24 AWG	1061 Style UL	-20 °C	80 °C	Solid	50 ft 500 ft 1000 ft	0.01 in	Poly-Vinyl Chloride (PVC)
Belden Inc. 9975 0041000	Hook-Up	0.04 in	300 V	Copper Tinned	Yellow	24 AWG	1061 Style UL	-20 °C	80 °C	Solid	1000 ft	0.01 in	Poly-Vinyl Chloride (PVC)
Belden Inc. 9975 002100	Hook-Up	0.04 in	300 V	Copper Tinned	Red	24 AWG	1061 Style UL	-20 °C	80 °C	Solid	100 ft	0.01 in	Poly-Vinyl Chloride (PVC)
Belden Inc. 9975 0021000	Hook-Up	0.04 in	300 V	Copper Tinned	Red	24 AWG	1061 Style UL	-20 °C	80 °C	Solid	50 ft 500 ft 1000 ft	0.01 in	Poly-Vinyl Chloride (PVC)
Belden Inc. 9975 0131000	Hook-Up	0.04 in	300 V	Copper Tinned	Blue	24 AWG	1061 Style UL	-20 °C	80 °C	Solid	1000 ft	0.01 in	Poly-Vinyl Chloride (PVC)
Belden Inc. 9975 0031000	Hook-Up	0.04 in	300 V	Copper Tinned	Orange	24 AWG	1061 Style UL	-20 °C	80 °C	Solid	1000 ft	0.01 in	Poly-Vinyl Chloride (PVC)
Belden Inc. 9975 0051000	Hook-Up	0.04 in	300 V	Copper Tinned	Green	24 AWG	1061 Style UL	-20 °C	80 °C	Solid	1000 ft	0.01 in	Poly-Vinyl Chloride (PVC)
Belden Inc. 9975 0091000	Hook-Up	0.04 in	300 V	Copper Tinned	White	24 AWG	1061 Style UL	-20 °C	80 °C	Solid	1000 ft	0.01 in	Poly-Vinyl Chloride (PVC)
