BQ500101DPCT
ActiveNEXFET POWER STAGE 8-VSON-CLIP -40 TO 125
Deep-Dive with AI
Search across all available documentation for this part.
BQ500101DPCT
ActiveNEXFET POWER STAGE 8-VSON-CLIP -40 TO 125
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | BQ500101DPCT |
|---|---|
| Applications | Synchronous Buck Converters |
| Current - Output / Channel | 10 A |
| Current - Peak Output | 15 A |
| Fault Protection | Shoot-Through |
| Features | Bootstrap Circuit |
| Interface | PWM |
| Load Type | Inductive |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 150 C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 8-PowerVFDFN |
| Supplier Device Package | 8-VSON (3.5x4.5) |
| Technology | Power MOSFET |
| Voltage - Supply [Max] | 5.5 V |
| Voltage - Supply [Min] | 4.5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| DigiKey | N/A | 1 | $ 1.93 | |
| 10 | $ 1.42 | |||
| 25 | $ 1.30 | |||
| 100 | $ 1.16 | |||
| 250 | $ 1.09 | |||
| 500 | $ 1.05 | |||
| 750 | $ 1.03 | |||
| 1250 | $ 1.01 | |||
| 1750 | $ 0.99 | |||
| 2500 | $ 0.98 | |||
| 6250 | $ 0.95 | |||
| Digikey | Cut Tape (CT) | 1 | $ 2.11 | |
| 10 | $ 1.89 | |||
| 25 | $ 1.79 | |||
| 100 | $ 1.52 | |||
| Digi-Reel® | 1 | $ 2.11 | ||
| 10 | $ 1.89 | |||
| 25 | $ 1.79 | |||
| 100 | $ 1.52 | |||
| Tape & Reel (TR) | 250 | $ 1.43 | ||
| 500 | $ 1.25 | |||
| 1250 | $ 1.04 | |||
| 2500 | $ 0.96 | |||
| 6250 | $ 0.93 | |||
| Mouser Electronics | N/A | 1 | $ 1.93 | |
| 10 | $ 1.30 | |||
| 100 | $ 1.16 | |||
| 250 | $ 1.09 | |||
| 500 | $ 1.03 | |||
| 1000 | $ 0.97 | |||
| 2500 | $ 0.94 | |||
| 5000 | $ 0.93 | |||
| Texas Instruments | SMALL T&R | 1 | $ 1.58 | |
| 100 | $ 1.31 | |||
| 250 | $ 0.94 | |||
| 1000 | $ 0.71 | |||
| Win Source Electronics | N/A | 35 | $ 1.48 | |
| 85 | $ 1.21 | |||
| 130 | $ 1.17 | |||
| 180 | $ 1.14 | |||
| 230 | $ 1.10 | |||
| 305 | $ 0.99 | |||
BQ500101 Series
NexFET Power Stage
| Part | Interface | Load Type | Current - Output / Channel | Features | Current - Peak Output | Technology | Package / Case | Applications | Supplier Device Package | Voltage - Supply [Max] | Voltage - Supply [Min] | Fault Protection | Mounting Type | Operating Temperature [Max] | Operating Temperature [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Texas Instruments BQ500101DPCT | PWM | Inductive | 10 A | Bootstrap Circuit | 15 A | Power MOSFET | 8-PowerVFDFN | Synchronous Buck Converters | 8-VSON (3.5x4.5) | 5.5 V | 4.5 V | Shoot-Through | Surface Mount | 150 C | -40 °C |
Description
General part information
BQ500101 Series
The bq500101 NexFET Power Stage is optimized for wireless power applications covering the WPC v1.2 medium power specification. The device can be used for both the rail voltage control in fixed frequency transmitter types as well as the coil drivers for both fixed and variable frequency types. This combination produces a high-current, high-efficiency, and high-speed switching device in a small 3.5 × 4.5 mm outline package. In addition, the PCB footprint is optimized to help reduce design time and simplify the completion of the overall system design.
The bq500101 NexFET Power Stage is optimized for wireless power applications covering the WPC v1.2 medium power specification. The device can be used for both the rail voltage control in fixed frequency transmitter types as well as the coil drivers for both fixed and variable frequency types. This combination produces a high-current, high-efficiency, and high-speed switching device in a small 3.5 × 4.5 mm outline package. In addition, the PCB footprint is optimized to help reduce design time and simplify the completion of the overall system design.
