C878AF35120AA0J

Active

KEMET

CAP FILM 12UF 5% 470VAC RADIAL

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsC878AF35120AA0J Spec Datasheet

C878AF35120AA0J

Active

KEMET

CAP FILM 12UF 5% 470VAC RADIAL

Deep-Dive with AI

DocumentsC878AF35120AA0J Spec Datasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	C878AF35120AA0J

Applications	Motor Run
Capacitance	12 µF
Dielectric Material	Metallized, Polypropylene (PP)
Height - Seated (Max) [Max] [z]	3.15 in
Height - Seated (Max) [Max] [z]	80 mm
Lead Spacing	13.4 mm
Lead Spacing	0.528 in
Mounting Type	Chassis Mount
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-25 °C
Package / Case	Radial, Can
Size / Dimension [diameter]	30 mm
Size / Dimension [diameter]	1.181 inches
Termination	Disconnect, Quick Connect
Tolerance	5 %
Voltage Rating - AC	470 V

C878AF Series

Part	Applications	Mounting Type	Capacitance	Voltage Rating - AC	Lead Spacing	Lead Spacing	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Package / Case	Termination	Termination	Termination	Operating Temperature [Min]	Operating Temperature [Max]	Dielectric Material	Tolerance	Size / Dimension [diameter]	Size / Dimension [diameter]
KEMET C878AF24800AA0J	Motor Run	Chassis Stud Mount	8 µF	470 V	0.394 in	10 mm	3.15 in	80 mm	Radial Can	0.25 in	6.3 mm	Quick Connect	-25 °C	85 °C	Metallized Polypropylene (PP)	5 %	30 mm	1.181 inches
KEMET C878AF24600AA1J	Motor Run	Chassis Stud Mount	6 µF	470 V	0.394 in	10 mm	3.15 in	80 mm	Radial Can	0.25 in	6.3 mm	Quick Connect	-25 °C	85 °C	Metallized Polypropylene (PP)	5 %	30 mm	1.181 inches
KEMET C878AF14400ZA4J	Motor Run	Chassis Stud Mount	4 µF	470 V					Radial Can			Quick Connect - 0.110" (2.8mm)	-25 °C	85 °C	Metallized Polypropylene (PP)	5 %
KEMET C878AF25100AA0J	Motor Run	Chassis Stud Mount	10 µF	470 V	0.394 in	10 mm	3.15 in	80 mm	Radial Can	0.25 in	6.3 mm	Quick Connect	-25 °C	85 °C	Metallized Polypropylene (PP)	5 %	35 mm	1.378 in
KEMET C878AF35120AA0J	Motor Run	Chassis Mount	12 µF	470 V	0.528 in	13.4 mm	3.15 in	80 mm	Radial Can			Disconnect Quick Connect	-25 °C	85 °C	Metallized Polypropylene (PP)	5 %	30 mm	1.181 inches
KEMET C878AF24400TF1J	Motor Run	Chassis Mount	4 µF	470 V	0.394 in	10 mm			Radial Can			Disconnect Quick Connect	-25 °C	85 °C	Metallized Polypropylene (PP)	5 %	35 mm	1.378 in
KEMET C878AF45160AA1J	Motor Run	Chassis Stud Mount	16 µF	470 V					Radial Can			Quick Connect - 0.110" (2.8mm)	-25 °C	85 °C	Metallized Polypropylene (PP)	5 %
KEMET C878AF34350AA4J	Motor Run	Chassis Stud Mount	3.5 µF	470 V	0.528 in	13.4 mm			Radial Can	0.25 in	6.3 mm	Quick Connect	-25 °C	85 °C	Metallized Polypropylene (PP)	5 %	35 mm	1.378 in
KEMET C878AF24500AA1J	Motor Run	Chassis Stud Mount	5 µF	470 V	0.394 in	10 mm	2.303 in	58.5 mm	Radial Can	0.25 in	6.3 mm	Quick Connect	-25 °C	85 °C	Metallized Polypropylene (PP)	5 %	25 mm	0.984 "
KEMET C878AF25120AA0J	Motor Run	Chassis Stud Mount	12 µF	470 V	0.394 in	10 mm	3.15 in	80 mm	Radial Can	0.25 in	6.3 mm	Quick Connect	-25 °C	85 °C	Metallized Polypropylene (PP)	5 %	35 mm	1.378 in

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 4.72
		10	$ 4.09
		86	$ 3.70

Description

General part information

C878AF Series

12 µF Film Capacitor 470V Polypropylene (PP), Metallized Radial, Can

Documents

Technical documentation and resources

C878AF35120AA0J Spec

Datasheet
