4-1437514-5

Active

TE Connectivity Raychem Cable Protection

SWITCH TACTILE

Search across all available documentation for this part.

Active

TE Connectivity Raychem Cable Protection

SWITCH TACTILE

Technical Specifications

Parameters and characteristics for this part

Specification	4-1437514-5

null

Part	Mounting Hole Diameter [diameter]	Mounting Hole Diameter [diameter]	Accepts Pin Diameter [Max] [diameter]	Accepts Pin Diameter [Min] [diameter]	Accepts Pin Diameter [Min] [diameter]	Accepts Pin Diameter [Max] [diameter]	Operating Temperature [Max]	Operating Temperature [Min]	Contact Finish Thickness	Contact Finish Thickness	Termination	Tail Type	Board Thickness	Board Thickness	Contact Finish	Pin Hole Diameter [diameter]	Pin Hole Diameter [diameter]	Length - Overall [x]	Length - Overall [x]	Accepts Square Pin Size [y]	Accepts Square Pin Size [x]	Accepts Square Pin Size [y]	Accepts Square Pin Size [x]	Contact Material
TE Connectivity Raychem Cable Protection 4-1437514-5
TE Connectivity Raychem Cable Protection 6-1437514-2	1.09 mm	0.043 in	0.53 mm	0.016 in	0.41 mm	0.021 in	105 ░C	-55 °C	180 µin	4.57 µm	Solder	No Tail	0.76 mm	0.03 in	Tin	0.74 mm	0.029 in	2.39 mm	0.094 in	0.018 in	0.28 mm	0.46 mm	0.011 in	Beryllium Copper

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Tactile Switch
