851-002-203R001

Active

MH Connectors

SENSOR CONNECTOR, VULCON SERIES, M5, MALE, 2 POSITIONS, SOLDER PIN, STRAIGHT PANEL MOUNT

Search across all available documentation for this part.

Active

MH Connectors

SENSOR CONNECTOR, VULCON SERIES, M5, MALE, 2 POSITIONS, SOLDER PIN, STRAIGHT PANEL MOUNT

Technical Specifications

Parameters and characteristics for this part

Specification	851-002-203R001

Color	Silver
Connector Type	Female Sockets, Plug
Contact Finish - Mating	Gold
Contact Finish Thickness - Mating	Flash
Contact Material	Brass
Ingress Protection	IP67 - Dust Tight, Waterproof
Insert Material	Polybutylene Terephthalate (PBT)
Material Flammability Rating	UL94 V-0
Mounting Feature	Bulkhead - Rear Side Nut
Number of Positions	2
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Orientation	Keyed
Primary Material	Metal
Shell Finish	Nickel
Shell Material	Brass
Shell Size - Insert	M5-2
Shielding	Shielded
Voltage Rating	60 VDC

Part	Contact Finish - Mating	Shell Finish	Voltage Rating	Connector Type	Material Flammability Rating	Ingress Protection	Number of Positions	Shell Size - Insert	Primary Material	Mounting Feature	Shell Material	Operating Temperature [Max]	Operating Temperature [Min]	Contact Material	Orientation	Shielding	Contact Finish Thickness - Mating	Color	Insert Material
MH Connectors 851-002-203R001	Gold	Nickel	60 VDC	Female Sockets Plug	UL94 V-0	IP67 - Dust Tight Waterproof	2	M5-2	Metal	Bulkhead - Rear Side Nut	Brass	85 °C	-40 °C	Brass	Keyed	Shielded	Flash	Silver	Polybutylene Terephthalate (PBT)
MH Connectors 851-002-103R001	Gold	Nickel	60 VDC	Male Pins Receptacle	UL94 V-0	IP67 - Dust Tight Waterproof	2	M5-2	Metal	Bulkhead - Front Side Nut	Brass	85 °C	-40 °C	Brass	Keyed	Shielded	Flash	Silver	Polybutylene Terephthalate (PBT)

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

2 Position Circular Connector Plug, Female Sockets Solder Cup
