PSK-S5B-3-L

Obsolete

CUI Inc.

AC/DC POWER SUPPLY SINGLE-OUT 3.3V 1A 3.3W 4-PIN TRAY

Deep-Dive with AI

Search across all available documentation for this part.

PSK-S5B-3-L

Obsolete

CUI Inc.

AC/DC POWER SUPPLY SINGLE-OUT 3.3V 1A 3.3W 4-PIN TRAY

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	PSK-S5B-3-L

Applications	ITE (Commercial)
Approval Agency	EN, CB Scheme, UL, IEC
Current - Output 1	1 A
Efficiency	68 %
Features	Universal Input
Mounting Type	Chassis Mount
Number of Outputs	1
Power (Watts)	3.3 W
Size / Dimension [x]	1.46 in
Size / Dimension [x]	37 mm
Size / Dimension [y]	24.5 mm
Size / Dimension [y]	0.96 in
Size / Dimension [z]	0.71 in
Size / Dimension [z]	18 mm
Standard Number	55024, 62368-1, 55032 Class A, 60950-1, 61000-3-2
Type	Enclosed
Voltage - Input [Max]	264 VAC, 370 VDC
Voltage - Input [Min]	100 V, 85 VAC
Voltage - Isolation	4000 V
Voltage - Output 1	3.3 V

PSK-S5B Series

DIN Rail Power Supplies 3.3W 3.3V 1000mA DIN-rail Mount

Part	Number of Outputs	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Voltage - Isolation	Efficiency	Approval Agency	Mounting Type	Current - Output 1	Voltage - Input [Max]	Voltage - Input [Min]	Features	Standard Number	Applications	Voltage - Output 1	Power (Watts)	Type	DC Voltage - Input (Max) [Max]	Input Type	AC Voltage - Input [Min]	AC Voltage - Input [Max]	Current - Output (Max) [Max]	DC Voltage - Input (Min) [Min]	Load Regulation	Line Regulation	Package / Case	Current - Output (Max)
CUI Inc. PSK-S5B-3-T	1	31.5 mm	26.8 mm	76 mm	1.24 in	1.06 in	2.99 in	4000 V	68 %	CB Scheme EN IEC UL	Chassis Mount	1 A	264 VAC 370 VDC	85 VAC 100 V	Universal Input	55024 55032 Class A 60950-1 61000-3-2 62368-1	ITE (Commercial)	3.3 V	3.3 W	Enclosed
CUI Inc. PSK-S5B-5-T	1	31.5 mm	26.8 mm	76 mm	1.24 in	1.06 in	2.99 in	4000 V	75 %	CB Scheme EN IEC UL	Chassis Mount	1 A	264 VAC 370 VDC	85 VAC 100 V	Universal Input	55024 55032 Class A 60950-1 61000-3-2 62368-1	ITE (Commercial)	5 V	5 W	Enclosed
CUI Inc. PSK-S5B-3-L	1	24.5 mm	18 mm	37 mm	0.96 in	0.71 in	1.46 in	4000 V	68 %	CB Scheme EN IEC UL	Chassis Mount	1 A	264 VAC 370 VDC	85 VAC 100 V	Universal Input	55024 55032 Class A 60950-1 61000-3-2 62368-1	ITE (Commercial)	3.3 V	3.3 W	Enclosed
CUI Inc. PSK-S5B-9-DIN	1	31.5 mm	31.4 mm	76 mm	1.24 in	1.24 "	2.99 in	4000 V	77 %	CB Scheme EN IEC UL					Universal Input	55024 55032 Class A 60950-1 61000-3-2 62368-1	ITE (Commercial)	9 V	5 W		370 V	AC or DC	85 VAC	264 VAC	560 mA	100 V
CUI Inc. PSK-S5B-9	1	24.5 mm	18 mm	37 mm	0.96 in	0.71 in	1.46 in		77 %	CB Scheme EN IEC UL	Through Hole		264 VAC 370 VDC	85 VAC 100 V	Universal Input	55024 55032 Class A 60950-1 61000-3-2 62368-1	ITE (Commercial)	9 V	5 W	Enclosed					560 mA		1 %	0.5 %	26-DIP Module 5 Leads
CUI Inc. PSK-S5B-3	1	24.5 mm	18 mm	37 mm	0.96 in	0.71 in	1.46 in		68 %	CB Scheme EN IEC UL	Through Hole		264 VAC 370 VDC	85 VAC 100 V	Universal Input	55024 55032 Class A 60950-1 61000-3-2 62368-1	ITE (Commercial)	3.3 V	3.3 W	Enclosed					1 A		1 %	0.5 %	26-DIP Module 5 Leads
CUI Inc. PSK-S5B-5-L	1	24.5 mm	18 mm	37 mm	0.96 in	0.71 in	1.46 in	4000 V	75 %	CB Scheme EN IEC UL	Chassis Mount	1 A	264 VAC 370 VDC	85 VAC 100 V	Universal Input	55024 55032 Class A 60950-1 61000-3-2 62368-1	ITE (Commercial)	5 V	5 W	Enclosed
CUI Inc. PSK-S5B-12-DIN	1	31.5 mm	31.4 mm	76 mm	1.24 in	1.24 "	2.99 in	4000 V	79 %	CB Scheme EN IEC UL					Universal Input	55024 55032 Class A 60950-1 61000-3-2 62368-1	ITE (Commercial)	12 V	5 W		370 V	AC or DC	85 VAC	264 VAC	420 mA	100 V
CUI Inc. PSK-S5B-15-T	1	31.5 mm	26.8 mm	76 mm	1.24 in	1.06 in	2.99 in	4000 V	79 %	CB Scheme EN IEC UL	Chassis Mount	330 mA	264 VAC 370 VDC	85 VAC 100 V	Universal Input	55024 55032 Class A 60950-1 61000-3-2 62368-1	ITE (Commercial)	15 V	5 W	Enclosed
CUI Inc. PSK-S5B-15	1	24.5 mm	18 mm	37 mm	0.96 in	0.71 in	1.46 in		79 %	CB Scheme EN IEC UL	Through Hole		264 VAC 370 VDC	85 VAC 100 V	Universal Input	55024 55032 Class A 60950-1 61000-3-2 62368-1	ITE (Commercial)	15 V	5 W	Enclosed							1 %	0.5 %	26-DIP Module 5 Leads	330 mA

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Description

General part information

PSK-S5B Series

DIN Rail Power Supplies 3.3W 3.3V 1000mA DIN-rail Mount

Documents

Technical documentation and resources

No documents available
