BQ24620EVM
ActiveEVAL MODULE FOR BQ24620
Deep-Dive with AI
Search across all available documentation for this part.
BQ24620EVM
ActiveEVAL MODULE FOR BQ24620
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | BQ24620EVM | BQ24620 Series |
|---|---|---|
| Battery Chemistry | - | Lithium Iron Phosphate |
| Battery Pack Voltage | - | 26 V |
| Charge Current - Max | - | 10 A |
| Current - Charging | - | Constant - Programmable |
| Embedded | False | False |
| Fault Protection | - | Over Current, Over Voltage, Short Circuit, Over Temperature |
| Function | Battery Charger | Battery Charger |
| Mounting Type | - | Surface Mount |
| Number of Cells | - | 1 |
| Number of Cells | - | 7 |
| Operating Temperature | - | 85 °C |
| Operating Temperature | - | -40 °C |
| Package / Case | - | 16-VFQFN Exposed Pad |
| Primary Attributes | 26 V | 26 V |
| Primary Attributes | Multi Cell-Li-ion / Li-Polymer | Multi Cell-Li-ion / Li-Polymer |
| Secondary Attributes | On-Board LEDs | On-Board LEDs |
| Supplied Contents | Board(s) | Board(s) |
| Supplier Device Package | - | 3.5 |
| Supplier Device Package | - | 3.5 |
| Supplier Device Package | - | 16-VQFN |
| Type | Power Management | Power Management |
| Utilized IC / Part | BQ24620 | BQ24620 |
| Voltage - Supply (Max) | - | 28 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| DigiKey | Box | 1 | $ 118.80 | |
| Digikey | Box | 1 | $ 118.80 | |
| Mouser Electronics | N/A | 1 | $ 118.80 | |
BQ24620 Series
Standalone 1-7 cell Buck battery charge controller for Lithium phosphate batteries
| Part | Supplier Device Package [x] | Supplier Device Package [y] | Supplier Device Package | Charge Current - Max [Max] | Current - Charging | Number of Cells [Min] | Number of Cells [Max] | Operating Temperature [Max] | Operating Temperature [Min] | Fault Protection | Battery Chemistry | Battery Pack Voltage [Max] | Package / Case | Voltage - Supply (Max) [Max] | Mounting Type | Function | Supplied Contents | Utilized IC / Part | Secondary Attributes | Embedded | Primary Attributes | Primary Attributes | Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Texas Instruments BQ24620RVAT | 3.5 | 3.5 | 16-VQFN | 10 A | Constant - Programmable | 1 | 7 | 85 °C | -40 °C | Over Current, Over Temperature, Over Voltage, Short Circuit | Lithium Iron Phosphate | 26 V | 16-VFQFN Exposed Pad | 28 V | Surface Mount | ||||||||
Texas Instruments BQ24620EVM | Battery Charger | Board(s) | BQ24620 | On-Board LEDs | 26 V | Multi Cell-Li-ion / Li-Polymer | Power Management | ||||||||||||||||
Texas Instruments BQ24620RVAR | 3.5 | 3.5 | 16-VQFN | 10 A | Constant - Programmable | 1 | 7 | 85 °C | -40 °C | Over Current, Over Temperature, Over Voltage, Short Circuit | Lithium Iron Phosphate | 26 V | 16-VFQFN Exposed Pad | 28 V | Surface Mount |
Description
General part information
BQ24620 Series
The bq24620 device is a highly integrated lithium phosphate switched-mode battery charge controller. The device offers a constant-frequency synchronous switching PWM controller with high-accuracy charge current and voltage regulation, charge preconditioning, termination, and charge status monitoring.
The bq24620 charges the battery in three phases: preconditioning, constant current, and constant voltage.
The bq24620 device is a highly integrated lithium phosphate switched-mode battery charge controller. The device offers a constant-frequency synchronous switching PWM controller with high-accuracy charge current and voltage regulation, charge preconditioning, termination, and charge status monitoring.
Documents
Technical documentation and resources
