Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | TMC457-EVAL | TMC457 Series |
|---|---|---|
| Applications | - | Medical |
| Embedded | MCU, 32-Bit | MCU, 32-Bit |
| Embedded | True | True |
| Function | - | Controller - Commutation, Direction Management |
| Interface | - | Step/Direction, SPI |
| Motor Type - AC, DC | - | Piezo |
| Motor Type - Stepper | - | Bipolar |
| Mounting Type | - | Surface Mount |
| Operating Temperature | - | 70 °C |
| Operating Temperature | - | 0 °C |
| Output Configuration | - | Step/Direction |
| Package / Case | - | 144-LBGA |
| Primary Attributes | Motors (Stepper) | Motors (Stepper) |
| Secondary Attributes | SPI Interface(s) | SPI Interface(s) |
| Step Resolution | - | >256 |
| Supplied Contents | Board(s) | Board(s) |
| Supplier Device Package | - | 144-FBGA (13x13) |
| Type | Power Management | Power Management |
| Utilized IC / Part | TMC457, TMC246 | TMC457, TMC246 |
| Voltage - Supply | - | 1.5 - 3.3 V |
