Technical Specifications
Parameters and characteristics for this part
| Specification | SPC58XXADPT176S |
|---|---|
| Contents | Board(s) |
| Type | MCU 32-Bit |
| Utilized IC / Part | SPC58xE/G |
SPC58NHADPT386S Series
32-bit Power Architecture MCU for Automotive General Purpose Applications - Chorus family
| Part | Core Size | Program Memory Size | Core Processor | RAM Size | Speed | Voltage - Supply (Vcc/Vdd) | Grade | EEPROM Size | Connectivity | Operating Temperature [Max] | Operating Temperature [Min] | Oscillator Type | Number of I/O | Supplier Device Package | Mounting Type | Peripherals | Qualification | Program Memory Type | Package / Case | Board Type | Interconnect System | Suggested Programming Environment | Type | Contents | Utilized IC / Part | Platform | RAM Size | Core Size [custom] | EEPROM Size | Voltage - Supply (Vcc/Vdd) [Max] | Voltage - Supply (Vcc/Vdd) [Min] | Data Converters |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
STMicroelectronics | 32-Bit Tri-Core | 6 MB | e200z4 | 768 x 8 | 180 MHz | 3.3 V 5 V | Automotive | 256 x 8 | CANbus Ethernet FlexRay I2C LINbus SPI | 150 °C | -40 °C | Internal | 64 | 176-eLQFP (24x24) | Surface Mount | DMA WDT | AEC-Q100 | FLASH | 176-LQFP Exposed Pad | |||||||||||||
STMicroelectronics | 32-Bit Tri-Core | 4 MB | e200z4 | 768 x 8 | 180 MHz | 3.3 V 5 V | Automotive | 256 x 8 | CANbus Ethernet FlexRay I2C LINbus SPI | 150 °C | -40 °C | Internal | 64 | 144-eTQFP (20x20) | Surface Mount | DMA WDT | AEC-Q100 | FLASH | 144-TQFP Exposed Pad | |||||||||||||
STMicroelectronics | Fixed | Evaluation Platform | Arduino R3 Shield | SPC5Studio | MCU 32-Bit | Board(s) | SPC58EC80 | Discovery | ||||||||||||||||||||||||
STMicroelectronics | MCU 32-Bit | Board(s) | SPC58xE/G | |||||||||||||||||||||||||||||
STMicroelectronics | Fixed | MCU 32-Bit | Board(s) | SPC58 | ||||||||||||||||||||||||||||
STMicroelectronics | 4 MB | e200z420 | 180 MHz | 3.3 V 5 V | Automotive | CANbus I2C LINbus SPI | 125 °C | -40 °C | Internal | 80 | 100-eTQFP (14x14) | Surface Mount | DMA | AEC-Q100 | FLASH | 100-TQFP Exposed Pad | 512 K | 32-Bit Dual-Core | 128 K | |||||||||||||
STMicroelectronics | 4 MB | e200z420 | 180 MHz | 3.3 V 5 V | CANbus Ethernet FlexRay I2C LINbus SPI | 125 °C | -40 °C | Internal | 64 | 176-eLQFP (24x24) | Surface Mount | DMA | FLASH | 176-LQFP Exposed Pad | 512 K | 32-Bit Dual-Core | 128 K | |||||||||||||||
STMicroelectronics | 4 MB | e200z4 | 180 MHz | Automotive | CANbus Ethernet FlexRay I2C LINbus SPI | 150 °C | -40 °C | External Internal | 120 | 144-eTQFP (20x20) | Surface Mount | DMA POR WDT | AEC-Q100 | FLASH | 144-TQFP Exposed Pad | 768 K | 32-Bit Dual-Core | 256 K | 1.26 V | 1.14 V | A/D 10/12b SAR | |||||||||||
STMicroelectronics | 6 MB | e200z4 | 180 MHz | 1.2 V 3.3 V 5 V | Automotive | CANbus Ethernet FlexRay I2C LINbus SPI | 125 °C | -40 °C | Internal | 64 | 176-eLQFP (24x24) | Surface Mount | DMA | AEC-Q100 | FLASH | 176-LQFP Exposed Pad | 608 K | 32-Bit Dual-Core | 256 K | |||||||||||||
STMicroelectronics | Evaluation Platform | MCU 32-Bit | Board(s) | SPC58xB/C |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 927.60 | |
Description
General part information
SPC58NHADPT386S Series
The SPC58EC-DIS is the ideal discovery board for accelerating development and securing a fast time-to-market, with a perfect balance among performances, functionalities and cost. Featuring SPC58 Chorus 4C line microcontrollers, it addresses a wide range of automotive applications such as body and gateway, in which safety and security needs are growing.
The SPC58EC-DIS allows full access to peripherals such as DSPI, LINFlexD, ISO CAN-FD. The new features satisfy the ASIL-B requirements.
The board provides full access to all CPU’s signals and GPIO’s, and offers compatibility with an Arduino shield, through dedicated connectors. Dedicated connectors allow plugging shields Arduino UNO-compatible; this feature makes it easy to expand the functionality of the SPC58EC-DIS.
