3EGG1-2
ActiveTE Connectivity Raychem Cable Protection
POWER ENTRY MODULE FILTERED M 3 POS 250VACVAC 3A FUSE ST 1 PORT
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 3EGG1-2 |
|---|---|
| Accomodates a Fuse | True |
| Approval Agency | UL, VDE, CSA |
| Connector Style | IEC 320-C14 |
| Connector Type | Receptacle, Male Blades - Module |
| Current Rating - Appliance Inlet | 3 A |
| Current Rating - Filter | 3 A |
| Filter Type | Filtered (EMI, RFI) - Commercial |
| Fuse Holder, Drawer | Fuse Holder |
| Mounting Type | Panel Mount, Flange |
| Panel Cutout Dimensions [x] | 28.96 mm |
| Panel Cutout Dimensions [y] | 33.02 mm |
| Termination | 0.25 in |
| Termination | 6.3 mm |
| Termination | Quick Connect |
| Voltage Rating - Appliance Inlet [Max] | 250 VAC |
| Voltage Rating - Appliance Inlet [Min] | 120 VAC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 23.94 | |
| 10 | $ 20.96 | |||
| 36 | $ 20.05 | |||
| 72 | $ 19.41 | |||
| 108 | $ 18.76 | |||
| 252 | $ 17.73 | |||
| 504 | $ 17.21 | |||
Description
General part information
Corcom GG Series
Power Entry Module, None Input, No Switch, Shielded, Vertical, 3 A, .250" FASTON Output, 250 VAC, Filtered, Corcom GG, Power Entry Modules
