DEVKIT ENS22-E NB-IOT

Active

Telit Cinterion

NB-IOT DEV KIT WITH ENS22 MODULE

Search across all available documentation for this part.

Active

Telit Cinterion

NB-IOT DEV KIT WITH ENS22 MODULE

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	DEVKIT ENS22-E NB-IOT	ENS22 Series

Antenna Type	-	Antenna Not Included
Contents	-	Board(s)
Data Rate	-	250 KBd
Frequency	1800 MHz, 900 MHz, 800 MHz, 850 MHz, 700 MHz	700 - 1800 MHz
Mounting Type	-	Surface Mount
Operating Temperature	-	85 °C
Operating Temperature	-	-40 °C
Package / Case	-	106-BLGA Module
Power - Output	-	23 dBmW
Protocol	-	LTE CAT.NB
RF Family/Standard	-	Cellular
Serial Interfaces	-	UART, USB
Supplied Contents	Board(s)	Board(s)
Utilized IC / Part	-	Hi2115, EVAL-DSB Adapter, DSB75, DSB-Mini
Voltage - Supply	-	4.2 V
Voltage - Supply	-	2.8 V

NB-IOT DEV KIT WITH ENS22 MODULE

Part	Frequency	Supplied Contents	Data Rate	Serial Interfaces	RF Family/Standard	Utilized IC / Part	Antenna Type	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Protocol	Power - Output	Package / Case	Voltage - Supply [Max]	Voltage - Supply [Min]	Contents
Telit Cinterion DEVKIT ENS22-E NB-IOT	700 MHz, 800 MHz, 850 MHz, 900 MHz, 1800 MHz	Board(s)
Telit Cinterion ENS22-C REL.1	700 MHz, 800 MHz, 850 MHz, 900 MHz, 1800 MHz		250 KBd	UART, USB	Cellular	Hi2115	Antenna Not Included	85 °C	-40 °C	Surface Mount	LTE CAT.NB	23 dBmW	106-BLGA Module	4.2 V	2.8 V
Telit Cinterion EVAL ENS22-C REL.1	700 MHz, 800 MHz, 850 MHz, 900 MHz, 1800 MHz					DSB-Mini, DSB75, EVAL-DSB Adapter										Board(s)

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 100.00

General part information

Cinterion® Cellular 700MHz, 800MHz, 850MHz, 900MHz, 1.8GHz Evaluation Board

Technical documentation and resources

No documents available
