| Adapter Series | - | BNC to F, F to F, N to N |
| Adapter Type | - | Plug to Jack, Jack to Jack |
| Body Finish | Nickel | Nickel |
| Body Material | Brass | Brass, Zinc |
| Cable Group | 62, RG-59 | RG-59TFE, 62, RG-59, RG-8, 213, 11, RG-174, 188, 316, RG-58, RG-6, AT&T 735A, Belden 8218, RG-11 Tri, Quad Shield |
| Cable Group | - | 213 |
| Center Contact Material | Brass | Brass, Bronze, Phosphor Bronze |
| Center Contact Plating | Gold | Gold, Nickel, Tin |
| Center Gender | - | Female to Female |
| Color | - | White |
| Connector Style | BNC | F Type, UHF, BNC, N Type, RCA |
| Connector Type | Male Pin, Plug | Male Pin, Plug, Female Socket, Jack, Plug, Non-Gendered |
| Contact Termination | Push On | Solder Cup, Push On, Solder, Crimp |
| Conversion Type | - | Between Series, Same Series |
| Convert From (Adapter End) | - | BNC Jack, Female Socket, F Jack, N Jack |
| Convert To (Adapter End) | - | Male Pin, F Plug, Female Socket, F Jack, N Jack |
| Dielectric Material | Polymethylpentene (PMP) | Polyoxymethylene (POM) Acetal, Polymethylpentene (PMP), Polytetrafluoroethylene (PTFE) |
| Fastening Type | Bayonet Lock | Bayonet Lock, Threaded |
| Features | - | Hardware Included |
| Frequency - Max [Max] | 4 GHz | 2 - 750 MHz |
| Height | - | 9.6 mm |
| Height | - | 0.378 " |
| Housing Color | Silver | Silver |
| Impedance | 50 Ohms | 50 - 75 Ohms |
| Impedance | - | Non-Constant |
| Includes | 1 Sleeve, 1 Connector | 1 Sleeve, 1 Connector, 1 Contact, 1 Insert, 1 Bushing |
| Material | - | Polyethylene (PE) |
| Mating Cycles | 500 | 500 |
| Mounting Feature | - | Flange, Bulkhead |
| Mounting Type | Free Hanging (In-Line) | Free Hanging (In-Line), Fastener |
| Number of Ports | 1 | 1 |
| Opening Size | - | 5.4 mm |
| Opening Size | - | 0.213 in |
| Operating Temperature [Max] | 85 °C | 85 - 165 °C |
| Operating Temperature [Min] | -55 °C | -65 - -55 °C |
| Shield Termination | Crimp | Crimp, Solder, Twist On |
| Style | - | Straight |
| Type Attributes | - | Half |
| Voltage Rating | 500 V | 500 V |
