TRAB24003P
ActiveTE Connectivity Raychem Cable Protection
RF ANT 2.4GHZ DOME N FM PAN 2.7"
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsVehicular Antenna Catalog
TRAB24003P
ActiveTE Connectivity Raychem Cable Protection
RF ANT 2.4GHZ DOME N FM PAN 2.7"
Deep-Dive with AI
DocumentsVehicular Antenna Catalog
Technical Specifications
Parameters and characteristics for this part
| Specification | TRAB24003P |
|---|---|
| Antenna Type | Dome |
| Applications | Wi-Fi, GSM |
| Frequency Range [Max] | 2.5 GHz |
| Frequency Range [Min] | 2.4 GHz |
| Gain | 3 dBi |
| Height (Max) | 68.58 mm |
| Height (Max) [Max] [z] | 2.7 in |
| Number of Bands | 1 |
| Power - Max [Max] | 100 W |
| RF Family/Standard | Cellular, WiFi |
| Termination | N Type Female |
| VSWR | 2 |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 66.53 | |
| 10 | $ 62.50 | |||
| 25 | $ 60.48 | |||
| 100 | $ 56.05 | |||
Description
General part information
TRAB24003 Series
RF ANTENNA GSM, Wi-Fi Dome N Type Female Panel Mount
