Specification	ERM8-010-01-S-D-EM2-L-TR

Connector Type	Header, Center Strip Contacts
Contact Finish	Gold
Contact Finish Thickness	30 µin
Features	Latches
Mounting Type	Straddle Mount, Board Edge
Number of Positions	20
Number of Rows	2
Pitch	0.031 in

ERM8-010 Series

Part	Mounting Type	Contact Finish	Connector Type	Features	Contact Finish Thickness	Height Above Board	Pitch	Number of Positions	Number of Rows	Mated Stacking Height Options
Samtec Inc. ERM8-010-01-S-D-RA-L-K-TR	Right Angle Surface Mount	Gold	Center Strip Contacts Header	Board Guide Latches Mounting Flange Pick and Place	30 µin	0.246 in	0.031 in	20	2
Samtec Inc. ERM8-010-02.0-S-DV	Surface Mount	Gold	Center Strip Contacts Header	Board Guide	30 µin	0.235 in	0.031 in	20	2	12mm 7mm 9mm
Samtec Inc. ERM8-010-05.0-S-DV-EGP-K-TR	Surface Mount	Gold	Center Strip Contacts Header	Board Guide Mating Guide Pick and Place	30 µin	0.351 in	0.031 in	20	2	10mm 12mm 15mm
Samtec Inc. ERM8-010-01-L-D-RA-L-K-TR	Right Angle Surface Mount	Gold	Center Strip Contacts Header	Board Guide Latches Mounting Flange Pick and Place	10 Ąin	0.246 in	0.031 in	20	2
Samtec Inc. ERM8-010-02.0-L-DV-K-TR	Surface Mount	Gold	Center Strip Contacts Header	Board Guide Pick and Place	10 Ąin	0.235 in	0.031 in	20	2	12mm 7mm 9mm
Samtec Inc. ERM8-010-05.0-S-DV-L-TR	Surface Mount	Gold	Center Strip Contacts Header	Board Guide Latches	30 µin	0.351 in	0.031 in	20	2	10mm 12mm 15mm
Samtec Inc. ERM8-010-05.0-S-DV-DS-L-TR	Surface Mount	Gold	Differential Pair Array MALE	Board Guide Latches	30 µin	0.351 in	0.031 in	20	2	10mm 12mm 15mm
Samtec Inc. ERM8-010-05.0-L-DV-L-TR	Surface Mount	Gold	Center Strip Contacts Header	Board Guide Latches	10 Ąin	0.351 in	0.031 in	20	2	10mm 12mm 15mm
Samtec Inc. ERM8-010-09.0-L-DV-K-TR	Surface Mount	Gold	Center Strip Contacts Header	Board Guide Pick and Place	10 Ąin	0.508 in	0.031 in	20	2	14mm 16mm 19mm
Samtec Inc. ERM8-010-05.0-S-DV-L-K-TR	Surface Mount	Gold	Center Strip Contacts Header	Board Guide Latches Pick and Place	30 µin	0.351 in	0.031 in	20	2	10mm 12mm 15mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

ERM8-010-01-S-D-EM2-L-TR | Datasheet
