Description
General part information
EC2-4.5 Series
General Purpose Relay DPDT (2 Form C) Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | EC2-4.5NU |
|---|---|
| Approval Agency | CSA, TUV, UL |
| Coil Current | 31.1 mA |
| Coil Resistance | 145 Ohms |
| Coil Type | Non Latching |
| Coil Voltage | 4.5 VDC |
| Contact Form | Form, 2 Form C, C, 2, DPDT |
| Contact Material | Silver Alloy, Gold Alloy |
| Contact Rating (Current) | 2 A |
| Load - Max Switching (Apparent Power) | 125 VA, 500 VA |
| Load - Max Switching (Real Power) | 60 W, 440 W |
| Mounting Type | Through Hole |
| Must Operate Voltage | 3.38 VDC |
| Must Release Voltage | 0.45 VDC |
| Operate Time | 2 ms |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Relay Type | General Purpose |
| Release Time | 1 ms |
| Switching Voltage AC (Max) | 250 VAC |
| Switching Voltage DC (Max) | 220 VDC |
| Termination Style | PC Pin |
