RT2805AGSP

Obsolete

Richtek USA Inc.

IC REG BUCK ADJ 5A 8SOP

Search across all available documentation for this part.

Obsolete

Richtek USA Inc.

IC REG BUCK ADJ 5A 8SOP

Technical Specifications

Parameters and characteristics commom to parts in this series

EVAL MODULE FOR RT2805AGSP

Part	Main Purpose	Current - Output	Supplied Contents	Voltage - Output	Frequency - Switching	Outputs and Type	Outputs and Type	Board Type	Regulator Topology	Utilized IC / Part	Voltage - Input [Min]	Voltage - Input [Max]	Output Configuration	Voltage - Input (Min) [Min]	Function	Voltage - Output (Min/Fixed)	Voltage - Output (Max) [Max]	Synchronous Rectifier	Number of Outputs	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Voltage - Input (Max) [Max]	Supplier Device Package	Topology	Output Type	Package / Case	Package / Case	Package / Case
Richtek USA Inc. EVB_RT2805AGSP	DC/DC, Step Down	5 A	Board(s)	2.4 V	500 kHz	Non-Isolated	1	Fully Populated	Buck	RT2805A	5.5 V	36 V
Richtek USA Inc. RT2805AGSP		5 A			500 kHz								Positive	5.5 V	Step-Down	1.222 V	26 V		1	85 °C	-40 °C	Surface Mount	36 V	8-SOP-EP	Buck	Adjustable	0.154 in	8-SOIC	3.9 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Buck Switching Regulator IC Positive Adjustable 1.222V 1 Output 5A 8-SOIC (0.154", 3.90mm Width) Exposed Pad
