PHASE MONITORING RELAY
Search across all available documentation for this part.
PHASE MONITORING RELAY
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
General part information
Phase Loss, Phase Sequence, Voltage Sensing AC 230VAC
Technical documentation and resources
No documents available
Parameters and characteristics commom to parts in this series
| Specification | SLA-230-ALE | SLA-230 Series |
|---|---|---|
| Circuit | DPDT (2 Form C) | DPDT (2 Form C) |
| Contact Rating @ Voltage | 5 A, 240 VAC | 5 - 240 A |
| Delay Time [Max] | 0.5 s | 0.5 s |
| Delay Time [Min] | 0.25 Sec | 0.25 Sec |
| Mounting Type | Chassis Mount | Socketable, Chassis Mount |
| Trip Range [Max] | 270 V AC | 270 V AC |
| Trip Range [Min] | 190 V AC | 190 V AC |
| Trip Status | Energized High/Low | Energized High/Low |
| Type | Phase Sequence, Phase Loss, Voltage Sensing AC | Phase Sequence, Phase Loss, Voltage Sensing AC |
| Voltage - Supply | 230 VAC | 230 VAC |
PHASE MONITORING RELAY
| Part | Voltage - Supply | Mounting Type | Trip Range [Min] | Trip Range [Max] | Contact Rating @ Voltage | Delay Time [Max] | Delay Time [Min] | Type | Trip Status | Circuit |
|---|---|---|---|---|---|---|---|---|---|---|
ATC SLA-230-ASA | 230 VAC | Socketable | 190 V AC | 270 V AC | 10 A, 240 VAC | 0.5 s | 0.25 Sec | Phase Loss, Phase Sequence, Voltage Sensing AC | Energized High/Low | |
ATC SLA-230-ALE | 230 VAC | Chassis Mount | 190 V AC | 270 V AC | 5 A, 240 VAC | 0.5 s | 0.25 Sec | Phase Loss, Phase Sequence, Voltage Sensing AC | Energized High/Low | DPDT (2 Form C) |
