8719 060U500
ActiveMULTIPAIR CABLE, AUDIO CONTROL, SHIELDED, 1 PAIR, 16 AWG, 500 FT, 152.4 M
Deep-Dive with AI
Search across all available documentation for this part.
8719 060U500
ActiveMULTIPAIR CABLE, AUDIO CONTROL, SHIELDED, 1 PAIR, 16 AWG, 500 FT, 152.4 M
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 8719 060U500 |
|---|---|
| Cable Type | Multi-Conductor |
| Conductor Insulation | Polyethylene (PE) |
| Conductor Material | Copper, Tinned |
| Conductor Strand [custom] | 19 Strands |
| Conductor Strand [custom] | 29 AWG |
| Features | Drain Wire |
| Jacket (Insulation) Diameter [diameter] | 0.313 " |
| Jacket (Insulation) Diameter [diameter] | 7.95 mm |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) |
| Jacket Color | Chrome |
| Length [x] | 500 ' |
| Length [x] | 152.4 m |
| Number of Conductors | 2 |
| Operating Temperature [Max] | 80 C |
| Operating Temperature [Min] | -20 C |
| Ratings | UL Style 20253 |
| Shield Coverage | 100 % |
| Shield Material | Aluminum |
| Shield Type | Foil |
| Wire Gauge | 16 AWG |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
8719 Series
The 8719 060U500 is a 1-pair Shielded Cable with 16AWG stranded tinned copper conductors and polyethylene insulation. This twist pair multi-conductor cable comes with a Beldfoil® aluminum foil-polyester tape shield (100% coverage), 18AWG stranded tinned copper drain wire and chrome PVC jacket. Belden paired cable deliver low voltage analog data and signal transmission within enclosures from controllers and I/O's to devices such as temperature and pressure sensors, relays, valves, meters, thermocouples, solenoids, actuators, contactors, push buttons and alarms.
