HW-16-17-T-S-280-SM

Active

Samtec Inc.

CONN HDR 16POS 0.1 STACK SMD TIN

Search across all available documentation for this part.

Active

Samtec Inc.

CONN HDR 16POS 0.1 STACK SMD TIN

Technical Specifications

Parameters and characteristics for this part

Part	Color	Number of Rows	Termination	Length - Post (Mating) [x]	Length - Post (Mating) [x]	Pitch [x]	Pitch [x]	Length - Overall Pin [x]	Length - Overall Pin [x]	Length - Stack Height [x]	Length - Stack Height [x]	Number of Positions	Contact Finish - Post (Mating)	Mounting Type	Row Spacing [x]	Row Spacing	Contact Finish Thickness - Post (Mating)	Contact Finish Thickness - Post (Mating)	Length - Stack Height [z]	Length - Stack Height [z]
Samtec Inc. HW-16-17-T-S-280-SM	Black	1	Solder	3.429 mm	0.135 in	2.54 mm	0.1 in	0.415 in	10.541 mm	7.112 mm	0.28 in	16	Tin	Surface Mount
Samtec Inc. HW-16-17-F-D-260-SM	Black	2	Solder	3.937 mm	0.155 in	2.54 mm	0.1 in	0.415 in	10.541 mm				Gold	Surface Mount	0.1 in	2.54 mm	3 Áin	0.076 Ám	0.26 in	6.604 mm
Samtec Inc. HW-16-17-L-S-415-SM-A	Black	1	Solder			2.54 mm	0.1 in	0.415 in	10.541 mm	10.541 mm	0.415 in	16	Gold	Surface Mount			10 Áin	0.25 Ám

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	14	$ 2.46

General part information

16 Position Header Spacer Connector 0.100" (2.54mm) Tin Surface Mount
