Description

General part information

NHD-4.3 Series

SSD1963 - LCD Controller Display Evaluation Board

Technical Specifications

Parameters and characteristics for this part

Specification	NHD-4.3-480272MF-34 CONTROLLER BOARD

Contents	Board
Embedded	No
Function	LCD Controller
Primary Attributes	and Character LCD Displays, COG Graphic, For TFT
Supplied Contents	Board(s)
Type	Display
Utilized IC / Part	SSD1963
