A2235H

Obsolete

Lantronix, Inc.

RF RCVR GPS 1.575GHZ MODULE

Search across all available documentation for this part.

Obsolete

Lantronix, Inc.

RF RCVR GPS 1.575GHZ MODULE

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

SiRFstarIV™ RF Receiver GPS 1.575GHz -163dBm On-Board, Patch Module

Technical documentation and resources

Specification	A2235H	A2235 Series

Antenna Connector	On-Board, Patch	On-Board, Patch
Applications	General Purpose	General Purpose
Current - Receiving	56 mA	56 mA
Data Interface	SPI	SPI
For Use With/Related Products	-	A2235-H
Frequency	1.575 GHz	1.575 GHz
Modulation or Protocol	GPS	GPS
Mounting Type	Surface Mount	Surface Mount
Operating Temperature [Max]	85 °C	85 °C
Operating Temperature [Min]	-40 °C	-40 °C
Package / Case	Module	Module
Sensitivity	-163 dBm	-163 dBm
Supplied Contents	-	Board(s)
Supplier Device Package	Module	Module
Type	-	GPS
Voltage - Supply	3.3 V	3.3 V

Part	Current - Receiving	Modulation or Protocol	Frequency	Voltage - Supply	Applications	Package / Case	Antenna Connector	Mounting Type	Data Interface	Sensitivity	Supplier Device Package	Operating Temperature [Max]	Operating Temperature [Min]	Type	Supplied Contents	For Use With/Related Products
Lantronix, Inc. A2235H	56 mA	GPS	1.575 GHz	3.3 V	General Purpose	Module	On-Board, Patch	Surface Mount	SPI	-163 dBm	Module	85 °C	-40 °C
Lantronix, Inc. A2235HB04			1.575 GHz											GPS	Board(s)	A2235-H
