ST14DD10

Active

E-Switch

SWITCH TOGGLE SPDT 20A 125V

Search across all available documentation for this part.

Active

E-Switch

SWITCH TOGGLE SPDT 20A 125V

Technical Specifications

Parameters and characteristics for this part

Specification	ST14DD10

Actuator Length [x]	13 mm
Actuator Material	Brass, Nickel Plated
Actuator Type	Standard Round
Bushing Thread	M12
Bushing Thread	1 x 1
Circuit	SPDT
Current Rating (Amps)	20 A
Electrical Life	6000 Cycles
Illumination	Non-Illuminated
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	0 °C
Panel Cutout Dimensions [diameter]	12 mm
Switch Function	Mom-Off-Mom
Termination Style	Quick Connect - 0.250" (6.3mm)
Voltage Rating - AC	125 V

Part	Operating Temperature [Max]	Actuator Material	Actuator Type	Current Rating (Amps)	Termination Style	Circuit	Bushing Thread	Bushing Thread	Switch Function	Electrical Life	Actuator Length [x]	Panel Cutout Dimensions [diameter]	Voltage Rating - AC	Illumination
E-Switch ST14DD10	85 °C	Brass Nickel Plated	Standard Round	20 A	Quick Connect - 0.250" (6.3mm)	SPDT	M12	1 x 1	Mom-Off-Mom	6000 Cycles	13 mm	12 mm	125 V	Non-Illuminated
E-Switch ST14DD00	85 °C	Brass Nickel Plated	Standard Round	20 A	Quick Connect - 0.250" (6.3mm)	SPDT	M12	1 x 1	Mom-Off-Mom	6000 Cycles	19.5 mm	12 mm	125 V	Non-Illuminated
E-Switch ST14CD00	85 °C	Brass Nickel Plated	Standard Round	20 A	Quick Connect - 0.250" (6.3mm)	SPDT	M12	1 x 1	On-Off-Mom	6000 Cycles	19.5 mm	12 mm	125 V	Non-Illuminated

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Toggle Switch SPDT Panel Mount
