Technical Specifications

Parameters and characteristics for this part

Specification	CF890-07-07

Cable Type	Multi-Conductor
Conductor Insulation	Poly-Vinyl Chloride (PVC)
Conductor Material	Copper, Bare
Features	Flame Retardant, Oil Resistant
Jacket (Insulation) Diameter [diameter]	0.354 in
Jacket (Insulation) Diameter [diameter]	8.99 mm
Jacket (Insulation) Material	Polyurethane (PU)
Jacket Color	Black
Length	Enter Number of Feet in Order Quantity
Number of Conductors	7
Ratings	UL Style 20940
Spool Size	1000 ft
Spool Size	304.8 m
Voltage	600 V
Wire Gauge	18 AWG

CF890 Series

Part	Number of Conductors	Wire Gauge	Jacket (Insulation) Material	Cable Type	Conductor Insulation	Ratings	Conductor Material	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Voltage	Spool Size	Spool Size	Features	Length	Jacket Color	Usage
Igus CF890-07-04	4	18 AWG	Polyurethane (PU)	Multi-Conductor	Poly-Vinyl Chloride (PVC)	UL Style 20940	Copper Bare	0.276 in	7.01 mm	600 V	1000 ft	304.8 m	Flame Retardant Oil Resistant	Enter Number of Feet in Order Quantity	Black
Igus CF890-10-04	4	17 AWG	Polyurethane (PU)	Multi-Conductor	Poly-Vinyl Chloride (PVC)	UL Style 20940	Copper Bare	0.276 in	7.01 mm	600 V			Flame Retardant Oil Resistant	Enter Number of Feet in Order Quantity	Black	Industrial Control
Igus CF890-25-25	25	13.5 AWG	Polyurethane (PU)	Multi-Conductor	Thermoplastic Elastomer (TPE)	UL Style 20940	Copper Bare	0.846 in	21.49 mm	600 V			Flame Retardant Oil Resistant	Enter Number of Feet in Order Quantity	Black	Industrial Control
Igus CF890-25-07	7	13.5 AWG	Polyurethane (PU)	Multi-Conductor	Thermoplastic Elastomer (TPE)	UL Style 20940	Copper Bare	0.472 in	11.99 mm	600 V			Flame Retardant Oil Resistant	Enter Number of Feet in Order Quantity	Black	Industrial Control
Igus CF890-07-25	25	18 AWG	Polyurethane (PU)	Multi-Conductor	Poly-Vinyl Chloride (PVC)	UL Style 20940	Copper Bare	0.531 in	13.49 mm	600 V	1000 ft	304.8 m	Flame Retardant Oil Resistant	Enter Number of Feet in Order Quantity	Black	Industrial Control
Igus CF890-07-07	7	18 AWG	Polyurethane (PU)	Multi-Conductor	Poly-Vinyl Chloride (PVC)	UL Style 20940	Copper Bare	0.354 in	8.99 mm	600 V	1000 ft	304.8 m	Flame Retardant Oil Resistant	Enter Number of Feet in Order Quantity	Black
Igus CF890-05-18	18	20 AWG	Polyurethane (PU)	Multi-Conductor	Poly-Vinyl Chloride (PVC)	UL Style 20940	Copper Bare	0.394 in	10.01 mm	600 V	1000 ft	304.8 m	Flame Retardant Oil Resistant	Enter Number of Feet in Order Quantity	Black	Industrial Control
Igus CF890-05-04	4	20 AWG	Polyurethane (PU)	Multi-Conductor	Poly-Vinyl Chloride (PVC)	UL Style 20940	Copper Bare	0.236 in	5.99 mm	600 V	1000 ft	304.8 m	Flame Retardant Oil Resistant	Enter Number of Feet in Order Quantity	Black	Industrial Control
Igus CF890-10-07	7	17 AWG	Polyurethane (PU)	Multi-Conductor	Poly-Vinyl Chloride (PVC)	UL Style 20940	Copper Bare	0.335 "	8.51 mm	600 V			Flame Retardant Oil Resistant	Enter Number of Feet in Order Quantity	Black	Industrial Control
Igus CF890-25-12	12	13.5 AWG	Polyurethane (PU)	Multi-Conductor	Thermoplastic Elastomer (TPE)	UL Style 20940	Copper Bare	0.591 in	15.01 mm	600 V			Flame Retardant Oil Resistant	Enter Number of Feet in Order Quantity	Black	Industrial Control

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Digi-Spool®, Continuous Spool	1	$ 3.56
		3	$ 3.31
		5	$ 3.18
		7	$ 3.10
		10	$ 3.04
		25	$ 2.85
		50	$ 2.70
		100	$ 2.58

Description

General part information

CF890 Series

7 Conductor Multi-Conductor Cable Black 18 AWG Enter Number of Feet in Order Quantity
