CF890-25-25

Active

Igus

CABLE 25COND 14AWG BLACK 1=1FT

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

CF890-25-25

Active

Igus

CABLE 25COND 14AWG BLACK 1=1FT

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	CF890-25-25

Cable Type	Multi-Conductor
Conductor Insulation	Thermoplastic Elastomer (TPE)
Conductor Material	Copper, Bare
Features	Flame Retardant, Oil Resistant
Jacket (Insulation) Diameter [diameter]	21.49 mm
Jacket (Insulation) Diameter [diameter]	0.846 in
Jacket (Insulation) Material	Polyurethane (PU)
Jacket Color	Black
Length	Enter Number of Feet in Order Quantity
Number of Conductors	25
Ratings	UL Style 20940
Usage	Industrial, Control
Voltage	600 V
Wire Gauge	13.5 AWG

CF890 Series

Part	Number of Conductors	Wire Gauge	Jacket (Insulation) Material	Cable Type	Conductor Insulation	Ratings	Conductor Material	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Voltage	Spool Size	Spool Size	Features	Length	Jacket Color	Usage
Igus CF890-07-04	4	18 AWG	Polyurethane (PU)	Multi-Conductor	Poly-Vinyl Chloride (PVC)	UL Style 20940	Copper Bare	0.276 in	7.01 mm	600 V	1000 ft	304.8 m	Flame Retardant Oil Resistant	Enter Number of Feet in Order Quantity	Black
Igus CF890-10-04	4	17 AWG	Polyurethane (PU)	Multi-Conductor	Poly-Vinyl Chloride (PVC)	UL Style 20940	Copper Bare	0.276 in	7.01 mm	600 V			Flame Retardant Oil Resistant	Enter Number of Feet in Order Quantity	Black	Industrial Control
Igus CF890-25-25	25	13.5 AWG	Polyurethane (PU)	Multi-Conductor	Thermoplastic Elastomer (TPE)	UL Style 20940	Copper Bare	0.846 in	21.49 mm	600 V			Flame Retardant Oil Resistant	Enter Number of Feet in Order Quantity	Black	Industrial Control
Igus CF890-25-07	7	13.5 AWG	Polyurethane (PU)	Multi-Conductor	Thermoplastic Elastomer (TPE)	UL Style 20940	Copper Bare	0.472 in	11.99 mm	600 V			Flame Retardant Oil Resistant	Enter Number of Feet in Order Quantity	Black	Industrial Control
Igus CF890-07-25	25	18 AWG	Polyurethane (PU)	Multi-Conductor	Poly-Vinyl Chloride (PVC)	UL Style 20940	Copper Bare	0.531 in	13.49 mm	600 V	1000 ft	304.8 m	Flame Retardant Oil Resistant	Enter Number of Feet in Order Quantity	Black	Industrial Control
Igus CF890-07-07	7	18 AWG	Polyurethane (PU)	Multi-Conductor	Poly-Vinyl Chloride (PVC)	UL Style 20940	Copper Bare	0.354 in	8.99 mm	600 V	1000 ft	304.8 m	Flame Retardant Oil Resistant	Enter Number of Feet in Order Quantity	Black
Igus CF890-05-18	18	20 AWG	Polyurethane (PU)	Multi-Conductor	Poly-Vinyl Chloride (PVC)	UL Style 20940	Copper Bare	0.394 in	10.01 mm	600 V	1000 ft	304.8 m	Flame Retardant Oil Resistant	Enter Number of Feet in Order Quantity	Black	Industrial Control
Igus CF890-05-04	4	20 AWG	Polyurethane (PU)	Multi-Conductor	Poly-Vinyl Chloride (PVC)	UL Style 20940	Copper Bare	0.236 in	5.99 mm	600 V	1000 ft	304.8 m	Flame Retardant Oil Resistant	Enter Number of Feet in Order Quantity	Black	Industrial Control
Igus CF890-10-07	7	17 AWG	Polyurethane (PU)	Multi-Conductor	Poly-Vinyl Chloride (PVC)	UL Style 20940	Copper Bare	0.335 "	8.51 mm	600 V			Flame Retardant Oil Resistant	Enter Number of Feet in Order Quantity	Black	Industrial Control
Igus CF890-25-12	12	13.5 AWG	Polyurethane (PU)	Multi-Conductor	Thermoplastic Elastomer (TPE)	UL Style 20940	Copper Bare	0.591 in	15.01 mm	600 V			Flame Retardant Oil Resistant	Enter Number of Feet in Order Quantity	Black	Industrial Control

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 16.40
		100	$ 15.75
		500	$ 15.13
		1000	$ 13.20

Description

General part information

CF890 Series

25 Conductor Multi-Conductor Cable Black 14 AWG Enter Number of Feet in Order Quantity
