470-0.75-5

Active

3M (TC)

TAPE ELECTROPLATING TAN 3/4"X5YD

Search across all available documentation for this part.

Active

3M (TC)

TAPE ELECTROPLATING TAN 3/4"X5YD

Technical Specifications

Parameters and characteristics for this part

Specification	470-0.75-5

Adhesive	Rubber
Backing, Carrier	Vinyl
Color	Tan
Length	4.6 m
Length	15 ft
Length	5 yd
Shelf Life	18 Months
Shelf Life Start	Date of Manufacture
Storage/Refrigeration Temperature [Max]	80 °F, 27 °C
Storage/Refrigeration Temperature [Min]	60 °F, 16 °C
Tape Type	Electroplating
Temperature Range	170 °F
Temperature Range	77 °C
Thickness	0.18 mm
Thickness	7.1 mils
Thickness	0.0071 in
Thickness - Adhesive [custom]	0.021 mm
Thickness - Adhesive [custom]	0.0008 "
Thickness - Adhesive [custom]	0.8 mils
Thickness - Backing, Carrier [custom]	6.3 mils
Thickness - Backing, Carrier [custom]	0.16 mm
Thickness - Backing, Carrier [custom]	0.0063 in
Usage	Sealing, Protection, Masking
Width	0.75 in
Width	19.05 mm
Width	0.75 in

Part	Storage/Refrigeration Temperature [Min]	Storage/Refrigeration Temperature [Max]	Backing, Carrier	Length	Length	Length	Thickness - Adhesive [custom]	Thickness - Adhesive [custom]	Thickness - Adhesive [custom]	Shelf Life Start	Shelf Life	Thickness - Backing, Carrier [custom]	Thickness - Backing, Carrier [custom]	Thickness - Backing, Carrier [custom]	Usage	Tape Type	Thickness	Thickness	Thickness	Width [x]	Width [x]	Temperature Range	Temperature Range	Color	Adhesive	Width	Width	Width
3M (TC) 470-1-5	16 °C 60 °F	27 °C 80 °F	Vinyl	4.6 m	15 ft	5 yd	0.021 mm	0.0008 "	0.8 mils	Date of Manufacture	18 Months	6.3 mils	0.16 mm	0.0063 in	Masking Protection Sealing	Electroplating	0.18 mm	7.1 mils	0.0071 in	25.4 mm	1 in	170 °F	77 °C	Tan	Rubber
3M (TC) 470-0.75-5	16 °C 60 °F	27 °C 80 °F	Vinyl	4.6 m	15 ft	5 yd	0.021 mm	0.0008 "	0.8 mils	Date of Manufacture	18 Months	6.3 mils	0.16 mm	0.0063 in	Masking Protection Sealing	Electroplating	0.18 mm	7.1 mils	0.0071 in			170 °F	77 °C	Tan	Rubber	0.75 in	19.05 mm	0.75 in
3M (TC) 470-12-5	16 °C 60 °F	27 °C 80 °F	Vinyl	4.6 m	15 ft	5 yd	0.021 mm	0.0008 "	0.8 mils	Date of Manufacture	18 Months	6.3 mils	0.16 mm	0.0063 in	Masking Protection Sealing	Electroplating	0.18 mm	7.1 mils	0.0071 in	304.8 mm	12 in	170 °F	77 °C	Tan	Rubber

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 13.40

General part information

Electroplating Tape Rubber Adhesive Tan 0.75" (19.05mm) 3/4" X 15' (4.6m) 5 yds
